MS1H4-10B30CB-A332R Inovance Servo Motor IP67 3000 Rpm For Industrial Automation
Price:
$300-600
MOQ:
Negotiable
Delivery Time:
1-3days
Product Description
MS1H4-10B30CB-A332R Inovance Servo Motor
Electrical Machinery MS1H4-10B30CB-A332R Brand New with 1 Year Warranty and Carton Box Packaging
Product Features
High-Quality Design
Precision engineering ensures long-lasting performance
Brand New Condition
Fresh out of the box, ready for immediate use
1-Year Warranty
Peace of mind with comprehensive protection
Secure Packaging
Carton box packaging for safe and convenient shipping
Supplier Information
Due to the variety of products it is impossible to upload all products to the Internet. If you can't find the products you want, you can contact online customer service.
- The more the quantity the cheaper the price
- After-sale technical service support
Main Products
PLC module, inverter, motor, HMI (touch panel), sensor, other attachments, etc.
Certification & Compliance
Dual-Certified Standards
CE (LVD/EMC) and UL5085 standards with complete technical file and EC Declaration of Conformity
Market Compliance
Meets EU carbon footprint requirements and North American industrial safety norms with no customs detention risk
Market Access
Helps you smoothly enter European and North American markets, avoiding project delays due to certification issues
Performance Advantages
Advanced Insulation
High-grade insulation material (H-class) + precision winding process with temperature rise ≤80K
Extended Service Life
40% longer service life than industry average, supports 24/7 continuous operation in -25°C~85°C environments
Cost Efficiency
Reduce unplanned downtime by 50% and cut annual maintenance costs by $10,000+ for medium-sized factories
Frequently Asked Questions
Do you provide technical files for CE/UL certification?
Yes! We offer complete technical files (including test reports, EC Declaration of Conformity) to ensure smooth customs clearance and project acceptance.
Can the product be customized for specific voltage and power?
Sure! Customization is available with MOQ 10 units, no extra cost for standard voltage/power adjustments.
What is the lead time for a 100-unit order?
2-3 days, with urgent production option for project deadlines.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | MS1H4-10B30CB-A332R |
| Frame Size | 40 mm |
| Rated Power | 0.1 kW |
| Rated Voltage | 220 V (Single-phase) |
| Rated Torque | 0.32 N*m |
| Maximum Torque | 1.12 N*m |
| Rated Current | 1.3 A |
| Rated Speed | 3000 rpm |
| Maximum Speed | 7000 rpm |
| Rotor Inertia | 0.102 kg*cm² |
| Encoder | 26-bit Multi-turn Absolute |
| Protection Class | IP67 |
| Insulation Class | F |
| Duty Type | S1 (Continuous) |
| Weight | 0.32 kg (0.48 kg with brake) |
| Recommended Driver | SV680-S1R6 |
| Mounting Flange | 40×40 mm |
| Shaft Diameter | Ø30 h7 |
| Applicable Scenarios | Fast point-to-point motion control, packaging machinery, printing equipment |
