KMX36NA Hydraulic Distribution Valve 70 Ton Excavator Main Control Valve
Price:
Negotiable
MOQ:
1
Delivery Time:
1-7 days
Brand:
MSGB
Product Description
Premium KMX36NA hydraulic distribution valve for 70–90 ton excavators, Kawasaki KMX series main control valve with load sensing, low pressure drop, OEM‑equivalent quality, global wholesale.
Working Principle
- Central flow distribution hub: Receives high‑pressure oil from dual main pumps and routes it to all working circuits.
- Pilot signal control: Pilot pressure shifts spools to adjust flow direction and speed.
- Load‑sensing feedback: LS shuttle valve detects load pressure and signals pumps for on‑demand supply.
- Pressure protection: Main relief valve limits max pressure to 34.3 MPa, protecting components.
- Multi‑function coordination: Pressure compensation ensures smooth simultaneous operation of multiple actuators.
- Flow regeneration: Recirculates return oil to boost speed and save energy.
Production Process
- Raw material inspection: High‑grade cast iron with certified chemical composition.
- Precision casting: Resin‑bonded sand mold for dense, defect‑free body.
- Stress relief annealing: Eliminates casting stress to prevent deformation.
- 5‑axis CNC machining: Bores, spools, and ports machined to ±0.02 mm tolerance.
- Spool hardening & chrome plating: HRC 58–62 + hard chrome for wear resistance.
- Hydraulic assembly & calibration: Load‑sensing and pressure compensation parameters fine‑tuned.
- 38 MPa pressure test: 15‑minute hold to screen leakage risks.
- Ultrasonic cleaning & anti‑rust packaging: Sealed bag + wooden crate for export.
Company Services
- 24/7 global technical support: Part matching, installation guidance, and troubleshooting for 70‑ton excavators.
- Pre‑shipment full inspection: Dimensional check, spool operation test, and hydraulic pressure test for every valve.
- Custom wholesale & OEM labeling: Volume discounts, private branding, and customized export packaging.
- Multiple logistics options: Sea, air, and express delivery with full tracking.
- One‑stop excavator parts: Main pumps, travel motors, swing motors, and hydraulic cylinders
FAQ
Q1: Which excavators does the KMX36NA valve fit?
A1: 70ton excavators, including Sany XCMG , and similar large mining models.
Q2: Is it a direct replacement for the original valve?
A2: Yes, 1:1 OEM match, bolt‑on installation without modification.
Q3: Is it in stock for bulk orders?
A3: Yes, abundant stock, fast global shipping for samples and bulk purchases.
