RMNS Integrated Low Voltage Switch Equipment

General

RMNS Integrated Low Voltage Switch Equipment(Named as Low Voltage Switchboard for Short in the following text) is a registered product of our company. RMNS low voitage switchboard is improved both in electric part choosing and in structure designing according to the trend of integrated low voltage switch equipment. The electric and mechanical performance of this product can meet the technical level of the original MNS product.

 This low voltage Switchboard can serve as control equipment for generating, transmitting, distributing electricity and transducing or consuming power in AC 50-60Hz electric systems which rated operating voltage should not above 660V.

This low voltage Switchboard can operating in general overland cases and can operating in maritime petroleum mining platform and nuclear power plant after special treatment.

This low voltage Switchboard is compliant with IEC439, the 5th section of VDE0660, the GB7251 integrated low voltage switch equipment standard and JB/T9661 integrated low voltage draw-out switch equipment standard.

Service Environmental Condition

2.1 The ambient temperature is between -5°C and +40°C, and the mean temperature of 24 hours is notabove +35°C.

2.2 Relative humidity is not above 50% when the ambient temperature is not above +40°C. when the temperature is relatively low, higher relative humidity is allowed (For example, the allowed relativehumidity is 90% when the ambient temperature is +20°C).

2.3 Altitude is not above 2000m

2.4 The temperature for transportation and storage is between-25°C and +50°C, and a temperature below +70°C is allowed within 24 hours.

2.5 Seismic intensity is below 9 degree.
