Industrial Cold Room Air Cooled Evaporator
Industrial Cold Room Air Cooled Evaporator
Product Details
The shell of cooler evaporator coil is generally made of plastic-sprayed iron plate, food-grade stainless steel plate or embossed aluminum plate. The cold room cooler has many advantages such as large heat exchange, convenient and simple, high corrosion resistance, and beautiful appearance. The heat exchange coil of the air cooler generally uses internal threads. The heat exchange copper tube is in close contact with the aluminum fin through a hydraulic tube expander, thereby reducing the contact distance and improving the heat transfer coefficient.
After the cold room cooler is produced, it goes through a strict decontamination process to ensure the cleanliness of the quality system. The cold storage cooler uses a high-efficiency outer rotor motor. The motor of this structure has the advantages of large air volume, high wind speed, and long service life. The cold storage cooler should be able to Install explosion-proof motors according to different needs.
Product Attributes
| Cold Storage Air Cooler | DD62 | DD75 | DD100 | |
| Air cooler motor | 3 | 3 | 3 | |
| Motor Type | Low-noise external rotor | Low-noise external rotor | Low-noise external rotor | |
| Motor Power | 420W | 420W | 420W | |
| Motor speed | 1350r/min | 1350r/min | 1350r/min | |
| Air volume | 6500m¾h | 6500m¾h | 6500m%/h | |
| Fan motor voltage | 380V/3N~/50HZ | 380V/3N~/50HZ | 380V/3N~/50HZ | |
| Fan blade diameter | 500mm | 500mm | 500mm | |
| Noise level | 72 dB(A) | 72 dB(A) | 73 dB(A) | |
| weight | 119kg | 119kg | 169kg | |
| Dimensions (mm) | Length | 2324 | 2324 | 2954 |
| Width | 627 | 627 | 627 | |
| Height | 704 | 704 | 704 | |
| Water inlet size | DN32 | DN32 | DN32 | |
| Heat exchange area | 64m² | 76m² | 102m² | |
Professional Customization: Manufacturing based on customer-provided drawings; a wide range of heat transfer tube options available.
 |
| Tube diameter (mm) | Tube spacing (mm) | Row spacing (mm) | Expansion height (mm) | Expansion height (mm) | Fin type |
| Tube diameter 15.88 | 38 | 32.91 | 1.8–6 | 1.8–3.6 | Flat fins / Corrugated fins (sinusoidal wave, V-shaped wave) |
| Tube diameter 12.7 | 31.75 | 27.5 | 1.8–6 | 1.8–6 | Flat fins / Corrugated fins (sinusoidal wave, V-shaped wave) |
| Tube diameter 9.52 | 25 | 21.65 | 1.4–5.5 | 1.4–3.2 | Flat fin / Corrugated fin / Louvered fin |
| Tube Diameter 7 | 25 | 21.65 | 1.2–3 | 1.2–2.5 | Flat fin / Corrugated fin / Louvered fin |
Various Fin Types Available
 |
Industrial Cubic Evaporator
| Air cooler is a kind of chilling equipment, which is suitable for a variety of cold room(such as construction cold rooms or combination cold rooms). There are variety of fin space designing, and suitable for different cold rooms of different temperature. It has the advantages of compact structure, beautiful appearance, light weight,does not occupy the storage area of the cold room, even room temperature, high efficiency, which coule quickly chill down the food and keep the food fresh.Model dd evaporator applies to -18 degree cold storage. Model DJ applies to -25 degree quick-frozen storage. |  |
Application
 |
 |
 |
| Pharmaceutical Cold Storage Warehouse | Cold storage warehouse for natural flowers | Meat cold storage warehouse |
Certificate
 |
 |
 |
Packing & Delivery
The normal package is wooden box. If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Lead Time: 20 - 40 days
Payment Terms: 50% T/T payment in advance, 50% T/T payment before delivery
Packing Condition: Standard export packing or customized packaging
 |
Our Advantages:
|
1.15+ Years Industry Experience: Specialized in HVAC & refrigeration heat exchangers manufacturing. 2.Full Customization Service: Custom size, material, fin design, anti-corrosion treatment and structure. 3.Strict Quality Control: Standard production and testing to ensure stable and durable performance. 4.OEM & ODM Available: Long-term cooperation for global HVAC OEM and engineering projects. 5.Fast Lead Time & Stable Delivery: Complete production lines to meet bulk and urgent orders. 6.Professional Technical Support: Quick quotation, technical selection and after-sales service worldwide. |
