Cubic Compact Air Cooler
Cubic Compact Air Cooler
Product Details
The air cooler ensures the highest standards of hygiene; all materials used in the unit are food-safe certified and easy to clean by wiping. Additionally, the large side panels feature a hinged design, allowing for easy opening for cleaning and inspection.
The air cooler features a high-quality aluminum casing with a powder-coated finish, providing excellent corrosion resistance.
An optional coil coating is also available to provide extra protection in moderately corrosive environments. The coil is fully coated, enhancing protection and extending the product's service life.
Product Attributes
| Cold Storage Air Cooler | DD15 | DD25 | DD40 | DD50 | |
| Air cooler motor | 1 | 2 | 2 | 2 | |
| Motor Type | Low-noise external rotor | Low-noise external rotor | Low-noise external rotor | Low-noise external rotor | |
| Motor Power | 230W | 230W | 420W | 420W | |
| Motor speed | 1350r/min | 1350r/min | 1350r/min | 1350r/min | |
| Air volume | 3800m¾/h | 3800m¾/h | 6500m%/h | 6500m%/h | |
| Fan motor voltage | 220V~/50HZ | 220V~/50HZ | 380V/3N~/50HZ | 380V/3N ~/50HZ | |
| Fan blade diameter | 400mm | 400mm | 500mm | 556mm | |
| Noise level | 70 dB(A) | 70 dB(A) | 70 dB(A) | 72 dB(A | |
| weight | 42kg | 61kg | 70kg | 92kg | |
| Dimensions (mm) | Length | 1024 | 1494 | 1589 | 1704 |
| Width | 508 | 508 | 627 | 627 | |
| Height | 593 | 593 | 699 | 700 | |
| Water inlet size | DN32 | DN32 | DN32 | DN32 | |
| Heat exchange area | 16m² | 26m² | 41m² | 51m² | |
Professional Customization: Manufacturing based on customer-provided drawings; a wide range of heat transfer tube options available.
 |
| Tube diameter (mm) | Tube spacing (mm) | Row spacing (mm) | Expansion height (mm) | Expansion height (mm) | Fin type |
| Tube diameter 15.88 | 38 | 32.91 | 1.8–6 | 1.8–3.6 | Flat fins / Corrugated fins (sinusoidal wave, V-shaped wave) |
| Tube diameter 12.7 | 31.75 | 27.5 | 1.8–6 | 1.8–6 | Flat fins / Corrugated fins (sinusoidal wave, V-shaped wave) |
| Tube diameter 9.52 | 25 | 21.65 | 1.4–5.5 | 1.4–3.2 | Flat fin / Corrugated fin / Louvered fin |
| Tube Diameter 7 | 25 | 21.65 | 1.2–3 | 1.2–2.5 | Flat fin / Corrugated fin / Louvered fin |
Various Fin Types Available
 |
Air Cooler & Evaporator for Cold Room
| This high-efficiency air cooler features a compact cubic structure, tailor-made for medium-sized cold rooms commonly found in supermarkets, restaurants and catering facilities. Its streamlined cubic shape allows flexible installation and space-saving layout, fitting neatly into limited indoor spaces without occupying excessive area. Adopting optimized heat exchange technology, it delivers stable and even cooling performance to maintain consistent indoor temperature. Durable casing and reliable fan components ensure long-term low-noise, energy-saving operation, perfectly meeting daily refrigeration and fresh-keeping demands of commercial catering and retail scenarios. |  |
Application
 |
 |
 |
| Pharmaceutical Cold Storage Warehouse | Cold storage warehouse for natural flowers | Meat cold storage warehouse |
Certificate
 |
 |
 |
Packing & Delivery
The normal package is wooden box. If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Lead Time: 20 - 40 days
Payment Terms: 50% T/T payment in advance, 50% T/T payment before delivery
Packing Condition: Standard export packing or customized packaging
 |
Our Advantages:
|
1.15+ Years Industry Experience: Specialized in HVAC & refrigeration heat exchangers manufacturing. 2.Full Customization Service: Custom size, material, fin design, anti-corrosion treatment and structure. 3.Strict Quality Control: Standard production and testing to ensure stable and durable performance. 4.OEM & ODM Available: Long-term cooperation for global HVAC OEM and engineering projects. 5.Fast Lead Time & Stable Delivery: Complete production lines to meet bulk and urgent orders. 6.Professional Technical Support: Quick quotation, technical selection and after-sales service worldwide. |
