Dewaxed Woven Reinforced Fiberglass Fabric Polymer Cloth Non Wax Insulation For Industrial Pipeline Boiler Wrapping
Price:
Negotiable
MOQ:
1000 pieces
Delivery Time:
Delivery within 15-30 days
Product Description
Dewaxed Woven Fiberglass Reinforced Polymer Cloth Heat Treated Non-Wax Insulation Fabric For Industrial Pipeline Boiler Wrapping
Product Description
When your work involves extreme heat, sparks, or fire hazards, having the right protective materials can make all the difference. That’s where comes in. Our fiberglass fabrics are engineered to keep people, equipment, and facilities safe while delivering unmatched performance in high-temperature environments.
Vermiculite Coated Fiberglass Fabrics are made from highly texturized continuous filament fiberglass yarn and enhanced with a proprietary vermiculite coating. This coating spreads heat evenly across the fabric, boosting resistance to high temperatures and abrasion.
With stronger bonding between the platelets and fabric, these fabrics reduce flaking, improve moisture resistance, and last longer. They withstand continuous temperatures up to 1500°F (815°C) and peak temperatures up to 2000°F (1095°C), with some styles available in black or reinforced with wire for added durability.
Features
Excellent resin permeability: After removing wax, the fibers are exposed, allowing epoxy resin, silicone resin and other matrix materials to fully penetrate, significantly improving the dry and wet mechanical strength of the laminated board and avoiding delamination defects.
High temperature resistance and thermal stability: No organic wax residue, long-term use temperature can reach 300 ℃~500 ℃ (depending on the glass fiber model), instantaneous temperature resistance is higher, and no volatiles or carbonization are produced at high temperatures, with good dimensional stability.
High electrical insulation performance: no conductive impurities on the surface, stable dielectric performance, high breakdown voltage, suitable for high-frequency circuit substrates and high-voltage electrical insulation wrapping.
Clean and dust-free surface: After dewaxing and subsequent water washing treatment, the fabric surface is smooth, hairless, and stain free, reducing fiber dust and facilitating subsequent coating and laminating processes, resulting in a smoother appearance of the finished product.
Color characteristics: After dewaxing treatment at 300 ℃~400 ℃, the finished product usually appears golden yellow or light brown, which is different from white or light yellow cloth that has not been dewaxed.
Chemical stability: retain the inherent acid and alkali resistance, corrosion resistance, non combustible characteristics of glass fiber, strong anti-aging ability, and long service life.
Processing adaptability: The texture is relatively soft (compared to untreated stiff fabric), easy to cut, sew, and punch, suitable for complex shape forming.
Technical Parameters
| Parameter | Specification Range |
|---|---|
| Product Name | Heat Cleaned Fiberglass Fabric |
| Process Type | Heat Cleaning / Thermal Desizing / Heat Treatment |
| Heat Treatment Temperature | 350°C – 650°C (660°F – 1200°F) |
| Weave Structure | Plain Weave / Twill Weave / Satin Weave / Lenor Weave |
| Weight (g/m²) | 50 – 900 g/m² |
| Thickness (mm) | 0.05 – 1.2 mm |
| Width (cm/in) | 80cm / 100cm / 127cm / 150cm / 200cm (31" / 39" / 50" / 59" / 79") |
| Residual Sizing Content | < 0.2% (typically < 0.1%) |
| Tensile Strength (Weft) – After | ≥ 450 – 3000 N/50mm |
| Strength Retention Rate | 85% – 92% |
| Elongation at Break | ≤ 3% – 5% |
| Temperature Resistance (Substrate) | 550°C – 800°C (1022°F – 1472°F) |
| Continuous Service Temperature | Up to 550°C (1022°F) |
| Resin Compatibility | Epoxy / Polyester / Vinyl Ester / Phenolic / Silicone / PTFE |
| Dimensional Stability | ≤ 0.5% |
| Wettability / Resin Flow | Excellent – resin wets out completely |
| Quality Control | LOI test / Tensile test / Thickness check / Visual inspection |
| Roll Length | 50m / 100m / 200m / Custom |
| Packaging | Moisture-proof paper + Plastic film + Woven bag / Carton |
| Certifications | ISO 9001 |
FAQ
Q. 1: How long is the sample time ? Does the sample fee can be returned?
Proofing is usually 3-5 working days. If the order reach or exceed behind MOQ quantity, proofing fee refunded. If not reached behind MOQ quantity, proofing fee will be taken by you.
Q. 2: About the sample what is the cost of transportation?
Q. 3: How long can I expect to get the sample?
The samples will be ready for delivery in 3-5days. The samples will be sent via international express and would be arrived within 3-5 days.
Q. 4: Do you accept customized orders?
Yes, we do. Your customized orders are always welcomed. Please kindly offer us your samples or drawings, so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.
Q. 5: Can we have our Logo or company name to be printed on your products or package?
Sure. Your Logo could be printed on your products by Hot Stamping, Printing, Embossing, UV Coating, Silk-screen Printing or Sticker.
Q. 6: How to order?
Please send us your purchase order by Email or call us sales line
We need to know the following information for your order before sending you PI.
1) Product information-Quantity, Specification(Size, Material, Technological if needed and Packing requirements etc.)
2) Delivery time required.
3) Shipping information-Company name, Street address, Phone&Fax number, Destination sea port.
4) Forwarder's contact details if there's any in China.
Q. 7: How can order the products without any acknowledge of import ?
We could arrange you shipping or air or express for you and deliver everything to your port or provide you door to door service.
Q. 8: Do you have stock ?
We have a warehouse with a lot of stock, and most of the products are in normal production. If we have stock, we can deliver immediately.
Q. 2: About the sample what is the cost of transportation?
The freight depends on weight, packing size and your country or province region, etc.
You can confirm by photo and video to save this money, If you become our old customer.
You can confirm by photo and video to save this money, If you become our old customer.
Q. 3: How long can I expect to get the sample?
The samples will be ready for delivery in 3-5days. The samples will be sent via international express and would be arrived within 3-5 days.
Q. 4: Do you accept customized orders?
Yes, we do. Your customized orders are always welcomed. Please kindly offer us your samples or drawings, so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.
Q. 5: Can we have our Logo or company name to be printed on your products or package?
Sure. Your Logo could be printed on your products by Hot Stamping, Printing, Embossing, UV Coating, Silk-screen Printing or Sticker.
Q. 6: How to order?
Please send us your purchase order by Email or call us sales line
We need to know the following information for your order before sending you PI.
1) Product information-Quantity, Specification(Size, Material, Technological if needed and Packing requirements etc.)
2) Delivery time required.
3) Shipping information-Company name, Street address, Phone&Fax number, Destination sea port.
4) Forwarder's contact details if there's any in China.
Q. 7: How can order the products without any acknowledge of import ?
We could arrange you shipping or air or express for you and deliver everything to your port or provide you door to door service.
Q. 8: Do you have stock ?
We have a warehouse with a lot of stock, and most of the products are in normal production. If we have stock, we can deliver immediately.
