High Temperature Resistance Colored Fiberglass Cloth Dyed Color 7628 Fiberglass Cloth
High Temperature Resistance Heat Protection 550 Degree Colored Dyed Color 7628 Fiberglass Cloth
Product Description
In the vast field of materials science, there is a composite material that is quietly integrating into many aspects of modern life with its unique properties and diverse applications, which is acrylic dyed glass fiber cloth. As a product that combines traditional glass fiber with modern polymer resin technology, it embodies the clever balance of material engineering in functionality, aesthetics, and practicality.
Fiberglass substrate is the skeleton and source of strength of the material. Glass fiber is an extremely fine fiber made from natural minerals such as quartz sand and limestone, which are melted at high temperatures and drawn. These fibers have extremely high tensile strength, excellent heat resistance and non flammability, and stable chemical properties that are not easily corroded. Weaving it into a fabric shape forms a lightweight, high-strength, and porous flexible substrate.
Features
High temperature resistance and flame retardancy: Glass fiber itself does not burn, and has excellent temperature resistance (usually able to withstand temperatures above 500 ℃, depending on the coating or post-treatment process), meeting strict fire safety standards.
Corrosion resistance and chemical stability: It has good resistance to chemicals such as acids, alkalis, and organic solvents, and is suitable for harsh environments.
Electrical insulation: With excellent dielectric properties, it is an ideal electrical insulation material.
Color persistence and aesthetics: Through specialized dyes or colorants, the colors are bright and strong, not easily faded, and meet decorative and identification needs.
Environmental Protection and Health: High quality products use non-toxic and odorless raw materials, comply with green building material standards, and are moisture-proof, mold proof, and insect bite proof.
Technical Parameters
| Parameter | Specification Range |
|---|---|
| Product Name | Colored / Dyed Fiberglass Fabric |
| Coloring Method | Pigment Coating (Acrylic-based) / Yarn Dyed / Surface Printing |
| Coating Type | Acrylic / Polyurethane / Silicone / Epoxy / Polyester |
| Glass Type | E-Glass / C-Glass / S-Glass / ECR-Glass |
| Weave Structure | Plain Weave / Twill Weave / Satin Weave / Lenor Weave |
| Color Evenness | Uniform / Consistent across width |
| Coating Adhesion | Excellent – no peeling or flaking |
| Coating Flexibility | High – no cracking on bending |
| Opacity / Coverage | Opaque – complete color coverage |
| Pigment Type | Inorganic pigments / Organic pigments |
| Tensile Strength (Warp) | ≥ 800 – 3500 N/50mm |
| Tensile Strength (Weft) | ≥ 600 – 3000 N/50mm |
| Abrasion Resistance | Good – surface coating protects fibers |
| Weather Resistance | Good for outdoor use (UV stabilized) |
| Dimensional Stability | ≤ 0.5% |
| Moisture Absorption | ≤ 1.0% |
| Application Methods for Color | Dip coating / Knife coating / Roll coating / Spray coating / Pad-dry-cure |
| Drying / Curing Temperature | 150°C – 200°C (302°F – 392°F) |
| Roll Length | 50m / 100m / 200m / Custom |
| Packaging | Core tube + PE film + Woven bag / Carton |
| Certifications |
ISO 9001 / RoHS / REACH / UL94 |
FAQ
Q. 1: How long is the sample time ? Does the sample fee can be returned?
Q. 2: About the sample what is the cost of transportation?
You can confirm by photo and video to save this money, If you become our old customer.
Q. 3: How long can I expect to get the sample?
The samples will be ready for delivery in 3-5days. The samples will be sent via international express and would be arrived within 3-5 days.
Q. 4: Do you accept customized orders?
Yes, we do. Your customized orders are always welcomed. Please kindly offer us your samples or drawings, so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.
Q. 5: Can we have our Logo or company name to be printed on your products or package?
Sure. Your Logo could be printed on your products by Hot Stamping, Printing, Embossing, UV Coating, Silk-screen Printing or Sticker.
Q. 6: How to order?
Please send us your purchase order by Email or call us sales line
We need to know the following information for your order before sending you PI.
1) Product information-Quantity, Specification(Size, Material, Technological if needed and Packing requirements etc.)
2) Delivery time required.
3) Shipping information-Company name, Street address, Phone&Fax number, Destination sea port.
4) Forwarder's contact details if there's any in China.
Q. 7: How can order the products without any acknowledge of import ?
We could arrange you shipping or air or express for you and deliver everything to your port or provide you door to door service.
Q. 8: Do you have stock ?
We have a warehouse with a lot of stock, and most of the products are in normal production. If we have stock, we can deliver immediately.
