Colorful Fiberglass Fabric Cloth 17oz 480gsm Waterproof 0.4mm Heat Resistance
Colorful Fiberglass Fabric Cloth 17oz 480gsm Waterproof 0.4mm Heat Resistance
Product Description
In shipbuilding, it is used for ship hull laminated structures to increase shell stiffness and resist water surface impacts. In the field of wind power generation, it is a commonly used reinforcing material for blade shells or certain internal sandwich structural panels, and the mesh helps to evenly distribute complex aerodynamic loads. In terms of building reinforcement, resin can be used for adhesive reinforcement on the surface of concrete components, and the mesh provides tensile strength and helps to evenly distribute the resin. In the manufacturing of some industrial containers, pipeline liners, and sports equipment, its application can also be seen, mainly due to its good formability and reliable reinforcement effect.
The effectiveness of its application is not the pursuit of advanced single performance, but the result of the synergy of multiple factors such as width parameters, grid structure, interface bonding, and stable chemical properties, making it a balanced and practical reinforcement component choice in various composite material systems.
Features
High temperature resistance and flame retardancy: Glass fiber itself does not burn, and has excellent temperature resistance (usually able to withstand temperatures above 500 ℃, depending on the coating or post-treatment process), meeting strict fire safety standards.
Corrosion resistance and chemical stability: It has good resistance to chemicals such as acids, alkalis, and organic solvents, and is suitable for harsh environments.
Electrical insulation: With excellent dielectric properties, it is an ideal electrical insulation material.
Color persistence and aesthetics: Through specialized dyes or colorants, the colors are bright and strong, not easily faded, and meet decorative and identification needs.
Environmental Protection and Health: High quality products use non-toxic and odorless raw materials, comply with green building material standards, and are moisture-proof, mold proof, and insect bite proof.
Technical Parameters
| Parameter | Specification Range |
|---|---|
| Product Name | Colored / Dyed Fiberglass Fabric |
| Coloring Method | Pigment Coating (Acrylic-based) / Yarn Dyed / Surface Printing |
| Base Fabric Thickness (mm) | 0.08 – 0.80 mm |
| Finished Thickness (mm) | 0.10 – 1.00 mm |
| Width (cm/in) | 100cm / 127cm / 150cm / 200cm (39" / 50" / 59" / 79") |
| Standard Colors | Black / White / Red / Blue / Green / Yellow / Orange / Gray |
| Color Evenness | Uniform / Consistent across width |
| Coating Adhesion | Excellent – no peeling or flaking |
| Coating Flexibility | High – no cracking on bending |
| Temperature Resistance | 100°C – 180°C (212°F – 356°F) continuous Up to 200°C (392°F) intermittent |
| Flame Resistance | Self-extinguishing / Flame retardant |
| UV Resistance | High – UV stable pigments |
| Water Resistance | Water repellent / Waterproof |
| Chemical Resistance | Resistant to: mild acids, alkalis, oils, grease |
| Abrasion Resistance | Good – surface coating protects fibers |
| Roll Length | 50m / 100m / 200m / Custom |
| Packaging | Core tube + PE film + Woven bag / Carton |
| Certifications |
ISO 9001 / RoHS / REACH / UL94 |
FAQ
Q. 1: How long is the sample time ? Does the sample fee can be returned?
Q. 2: About the sample what is the cost of transportation?
You can confirm by photo and video to save this money, If you become our old customer.
Q. 3: How long can I expect to get the sample?
The samples will be ready for delivery in 3-5days. The samples will be sent via international express and would be arrived within 3-5 days.
Q. 4: Do you accept customized orders?
Yes, we do. Your customized orders are always welcomed. Please kindly offer us your samples or drawings, so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.
Q. 5: Can we have our Logo or company name to be printed on your products or package?
Sure. Your Logo could be printed on your products by Hot Stamping, Printing, Embossing, UV Coating, Silk-screen Printing or Sticker.
Q. 6: How to order?
Please send us your purchase order by Email or call us sales line
We need to know the following information for your order before sending you PI.
1) Product information-Quantity, Specification(Size, Material, Technological if needed and Packing requirements etc.)
2) Delivery time required.
3) Shipping information-Company name, Street address, Phone&Fax number, Destination sea port.
4) Forwarder's contact details if there's any in China.
Q. 7: How can order the products without any acknowledge of import ?
We could arrange you shipping or air or express for you and deliver everything to your port or provide you door to door service.
Q. 8: Do you have stock ?
We have a warehouse with a lot of stock, and most of the products are in normal production. If we have stock, we can deliver immediately.
