2025 10th Gen Industrial Mini ITX DDR4 Motherboard with CPU Core I3 I5 10210U I7 10510U DP VGA 2*SATA3.0 Mainboard
Price:
$160-170 / piece
MOQ:
1 piece
Delivery Time:
Negotiable
Brand:
HH/OEM/ODM
Product Description
Product Description
Product Name:
Industrial motherboard 10th gen I7-10510U
support Max.32GB HD-MI DP LVDS 2*SATA3.0/1*MSATA3.0/1000M lan 4K display
support Max.32GB HD-MI DP LVDS 2*SATA3.0/1*MSATA3.0/1000M lan 4K display
Features:
1. Supporting 4K,at 60Hz Display Output;
2. Supporting Memory type DDR4-2133/2400,Max.16GB RAM;
3. Supporting OPS Card,OPS Mini PC Chassis;
4. Supporting Intel FCLGA1151 Sockets.
2. Supporting Memory type DDR4-2133/2400,Max.16GB RAM;
3. Supporting OPS Card,OPS Mini PC Chassis;
4. Supporting Intel FCLGA1151 Sockets.
Specification
size | 170mm*170mm | ||
CPU | 10th gen Comet Lake CPU:I3-10110U,I5-10210U,I7-10510UFHD | ||
RAM supply | 2*NB-DDR4 slot,supplrt 2133/2400/2666MHz RAM,the maximum support 32GB | ||
Power supply | 1*DC_IN | 12V/19VVoltage,DC is 2.5MM The power consumption of the motherboard is about 85W at full load. It is recommended to use 12V7A or above power supply | |
1*DC_ATX | |||
display | Integrated In tel UHD Graphics ultra-core graphics card, support single display, dual display/triple display copy, dual display/triple display expansion, single display under DOS | ||
1*VGA_OUT pin | Support the highest resolution 1920*1200@60HZ (12Pin,1*12Pin,2.0mm) | ||
1*VGA DB15 port | Support the highest resolution 1920*1200@60HZ | ||
1*DP poet | Support 4K resolution 4096/3840*2160@60HZ | ||
Choose one of VGA interface and DP interface | |||
1*HD MI 1.4 port | Support 4K resolution 4096/3840*2160@30HZ | ||
1*HD MI_CON pin | Support 4K resolution 4096/3840*2160@30HZ (16Pin,2*8Pin,2.0mm) | ||
1*EDP pin | Support 4K resolution 4096/3840*2160@60HZ (30Pin,2*15Pin,2.0mm) | ||
1*EDP_PWR pin | EDP Voltage control pin (6Pin,2*3Pin,2.0mm) | ||
1*LVDS pin | Support resolution 1920*1080@60HZ (30Pin,2*15Pin,2.0mm) | ||
1*LVDS_PWR pin | LVDS Voltage control pin (6Pin,2*3Pin,2.0mm) | ||
1*INVERT pin | LVDS Backlight switch backlight brightness adjustment control (6Pin,1*6Pin,2.0mm) | ||
1*BKLT-PWR1 | LVDS Backlight voltage control pin | ||
Choose one of LVDS pin and EDP pin | |||
Network functiuon | 1*LAN port | Realtek 8111H Gigabit network card chip, support Wake on LAN and PXE diskless boot function | |
1*Mini-PCIE port | Support WIFI/3G/4G/GPS/Blu etooth module, etc., optional support MSATA | ||
Hard Disk Function | 1*M.2 port | Support M.2 2280 by default, 2242 is optional; NVME (PCIE) protocol by default, SATA protocol can be changed | |
1*SATA1 port | Standard SATA3.0 hard disk interface, maximum transfer speed 6.0 Gbps | ||
Choose one of SATA1 signal and MSATA signal, support SATA1 by default | |||
1*SATA2 port | Standard SATA3.0 hard disk interface, maximum transfer speed 6.0 Gbps | ||
1*SATA_PWR1 pin | Hard disk power supply pin, available for power 5V,12V. (4Pin,1*4Pin,2.54mm) | ||
1*SATA_PWR2 pin | Hard disk power supply pin, available for power 5V,12V. (4Pin,1*4Pin,2.54mm) | ||
Other I/O | COM1/COM2 pin | Serial port, COM1 supports RS232, RS422/RS485 is optional (9Pin,2*5Pin,2.54mm) | |
COM3~COM6 pin | Serial port, support standard RS232; (39Pin,2*20Pin,2.0mm) | ||
1*JCOM1 pin | Control COM1 pin 9 voltage 0V/5V/12V optional (6Pin,2*3Pin,2.0mm) | ||
1*JCOM2 pin | Control COM2 pin 9 voltage 0V/5V/12V optional (6Pin,2*3Pin,2.0mm) | ||
1*SIM_CARD Card slot | Support SIM card, SIM card is required when using 3G/4G | ||
1*FAN2 pin | CPUFan pin, support temperature control (3Pin,1*3Pin,2.54mm) | ||
1*FAN3 pin | System fan pin, full speed, does not support temperature control (3Pin,1*3Pin,2.54mm) | ||
1*CLR_CMOS pin | Mainboard discharge, reset pins (3Pin,1*3Pin,2.0mm) | ||
1*J_GPIO pin | GPIO Control pin (10Pin,2*5Pin,2.0mm) | ||
Operating environment | Working temperature: -20℃~60℃; Working humidity: 5%~95% relative humidity, non-condensing | ||
BIOS | AMI BIOS,Support power-on boot, timing boot, remote switch machine intelligent identification | ||
Watch Dog | Watchdog programming, support hardware reset function(256 level,0~255 second) | ||
operating system | Support Windows 10 64,Linux | ||
Packing & Delivery
Packaging & Shipping
Packing
Before delivery,we guarantee that every item will be tested and carefully packed with individual Anti-static bubble bag and
separated by stiff cardboards in carton boxes.
1Piece/Carton(G.W. : 1.0-1.5KG);
5Pieces/Carton(G.W. : 5.0-7.5KG);
10Pieces/Carton(G.W. : 10.0-15.0KG);
Before delivery,we guarantee that every item will be tested and carefully packed with individual Anti-static bubble bag and
separated by stiff cardboards in carton boxes.
1Piece/Carton(G.W. : 1.0-1.5KG);
5Pieces/Carton(G.W. : 5.0-7.5KG);
10Pieces/Carton(G.W. : 10.0-15.0KG);
