2025 Hot Sale 5th Gen I3 5005U I3 5010U I5 5200U I5 5250U I5 5300U Processor EDP Mini ITX DDR3 Core I5 Motherboard
Price:
$61-72 / piece
MOQ:
1 piece
Delivery Time:
Negotiable
Brand:
HH/OEM/ODM
Product Description
Product Description
Specification
HYH310 Motherboard Spec. | ||
Size | 170mm(L)*170mm(W)*20mm(H) | |
CPU | Support 5th generation CPU: I3-5010U, I5-5200U, I7-5500U, etc. | |
Chipset | Broadwell-U Express Chipset | |
Memory | 1*NB-DDR3 SODIMM memory slot, supports 1600MHz memory, low voltage 1.35V, maximum support 8GB | |
Power supply | 1*DC_IN ;1*DC_ATX Supports 12V voltage, the inner diameter of the DC head is 2.5MM The motherboard consumes about 40W when fully loaded. It is recommended to use a 12V5A or higher power supply | |
Display | Support single display, dual display copy, dual display expansion, single display under DOS, Intel HD Graphics 5500 graphics controller. 1*VGA DB15 interface: Supports the highest resolution of 1920 * 1200@60HZ 1*VGA_OUT pin: Supports the highest resolution of 1920 * 1200@60HZ (12Pin, 1*12Pin, 2.0mm) 1*HDMI 1.4 interface: Support 4K resolution 4096/3840 * 2160@30HZ 1*HDMI_CON pin: Support 4K resolution 4096/3840 * 2160@30HZ (16Pin, 2*8Pin, 2.0mm) 1*EDP pin: Support 4K resolution 3840 * 2160@60HZ (30Pin, 2*15Pin, 2.0mm) 1*EDP_PWR pin: EDP working voltage control pin (6Pin, 2*3Pin, 2.0mm) | |
Network | 1/2*RJ45 LAN interface: Optional RTL8111F Gigabit/RTL8105E 100M network card chip, support network wake-up and PXE diskless boot function. 1*Mini-PCIE interface: Support WIFI | |
Hard disk | 1*SATA1 interface:Standard SATA3.0 hard disk interface, maximum transmission speed 6.0 Gbps 1*SATA2 interface: Standard SATA3.0 hard disk interface, maximum transmission speed 6.0 Gbps 1*MSATA interface: Support MSATA disk 1*SATA_PWR1 pin: Hard disk power supply pin, can take 5V, 12V power. (4Pin, 1*4Pin, 2.54mm) 1*SATA_PWR2 pin: Hard disk power supply pin, can take 5V, 12V power. (4Pin, 1*4Pin, 2.54mm) | |
Sound | Integrated Cmedia HS-100B high-fidelity USB audio chip 1*LIN_OUT interface: Support audio output (green) 1*MIC_IN interface: Support microphone input (red) 1*INT_SPK pin: The amplifier supports 8 ohm 5 watt speaker dual channel output (4Pin, 1*4Pin, 2.0mm) | |
USB | 2*USB3.0 interface: Rear standard USB3.0 interface 2*USB2.0 interface: Rear standard USB2.0 interface 1*F_USB3 pin: Front USB2.0 pin, one set has 2*USB2.0 (9Pin, 2*5Pin, 2.54mm) F_USB3 No signal on pins 2/4/6/8 by default 1*F_USB4 pin: Front USB2.0 pin, one set has 2*USB2.0 (9Pin, 2*5Pin, 2.54mm) | |
Switch | 1*F_PANEL pin: Switch, power light, hard disk light, restart pin (9Pin, 2*5Pin, 2.54mm) 1*AUTO_SW pin: Hardware control power-on pin (3Pin, 1*3Pin, 2.0mm) | |
Other I/O | 1*COM1 pin: Serial port, only supports RS232 (9Pin, 2*5Pin, 2.54mm) 1*JCOM1 pin: Control COM1 pin 9 voltage 0V/5V/12V optional (6Pin, 2*3Pin, 2.0mm) 1*SIM_CARD slot: Support SIM card, SIM card is required when using 3G/4G 1*CLR_CMOS pin: Motherboard reset and discharge pin (2Pin, 1*2Pin, 2.54mm) 1*SYS_FAN pin: System fan pin, full speed, does not support temperature control (3Pin, 1*3Pin, 2.54mm) 1*CPU_FAN pin: CPU fan pin, supports temperature control (3Pin, 1*3Pin, 2.54mm) 1*J_GPIO pin: Standard GPIO pin (10Pin, 2*5Pin, 2.0mm) | |
Operating Environment | Working temperature: -20℃~60℃; Working humidity: 5%~95% relative humidity, no condensation | |
BIOS | AMI BIOS, supports power-on, scheduled power-on, remote power on and off, and intelligent device identification | |
Watch Dog | Watchdog programming, support hardware reset function (256 levels, 0~255 seconds) | |
Operating system | Supports Win10, Win8, Win7, Linux, etc. | |
Packing & Delivery
Packaging & Shipping
Packing
Before delivery,we guarantee that every item will be tested and carefully packed with individual Anti-static bubble bag and
separated by stiff cardboards in carton boxes.
1Piece/Carton(G.W. : 1.0-1.5KG);
5Pieces/Carton(G.W. : 5.0-7.5KG);
10Pieces/Carton(G.W. : 10.0-15.0KG);
Before delivery,we guarantee that every item will be tested and carefully packed with individual Anti-static bubble bag and
separated by stiff cardboards in carton boxes.
1Piece/Carton(G.W. : 1.0-1.5KG);
5Pieces/Carton(G.W. : 5.0-7.5KG);
10Pieces/Carton(G.W. : 10.0-15.0KG);
