2025 Mini ITX Motherboard Haswell 4th Gen I5 4200U Mainboard With DDR3-8G DC12V/19V MSATA Win10 2/6*COM
Price:
$60-65 / piece
MOQ:
1 piece
Delivery Time:
Negotiable
Brand:
HH/OEM/ODM
Product Description
Product Description
Specification
Size | 170mm(L)*170mm(W)*20mm(H) | ||
Processor | supports 4th generations of CPU: I3-4010U, I5-4200U, I7-4500U, etc. | ||
Chipset | Haswell-U Express Chipset | ||
Memory | 1*DDR3 SODIMM memory slot, supports 1600MHz memory , low voltage 1.35V , maximum support 8GB | ||
Power supply | 1*DC_IN ; 1*DC_ATX Supports 12V/19V voltage, the inner diameter of the DC head is 2.5MM Motherboard power consumption: about 30W. It is recommended to use a 12V5A or higher power supply | ||
Display | Integrated Intel® HD 4400 graphics controller , supports single display, dual display / triple display copy, dual display / triple display expansion, single display under DOS 1*VGA DB15 interface: Support resolution 1920*1080@60HZ 1*VGA_OUT pin:Support resolution 1920*1080@60HZ (12Pin, 1*12Pin, 2.0mm) 1*HDMI 1.4 interface: Support resolution 4096/3840*2160@30HZ 1*HDMI_CON pin: Support resolution 4096/3840*2160@30HZ (16Pin, 2*8Pin, 2.0mm) 1*LVDS pin: Support resolution 1920*1080@60HZ (30Pin, 2*15Pin, 2.0mm) 1*VCC_SEL pin: LVDS voltage control pin (6Pin, 2*3Pin, 2.0mm) 1*INVERT pin: LVDS backlight switch control pin (6Pin, 1*6Pin, 2.0mm) 1*BKLT_CTRL pin: LVDS backlight brightness adjustment pin (4Pin, 1*4Pin, 2.0mm) | ||
Network | 1*RJ45 LAN interface: RTL8111 F Gigabit network card chip , supports network wake-up and PXE diskless boot functions . 1*Mini-PCIE interface: Support WIFI/3G/4G | ||
Hard disk | 1*MSATA interface: Support MSATA disk 2*SATA interface: Standard SATA3.0 hard disk interface, maximum transmission speed 6.0 Gbps 2*SATA_PWR pin: Hard disk power supply pin, can take 5V, 12V power. (4Pin, 1*4Pin, 2.54mm) | ||
Sound | Integrated Realtek ALC662 HD digital audio decoder , 6-channel high-fidelity audio controller. 1*LIN_OUT interface: Support audio output (green) 1*MIC_IN interface: Support microphone input (red) 1*INT_SPK pin: The amplifier supports 8 ohm 5 watt speaker dual channel output (4Pin, 1*4Pin, 2.0mm) 1*F_AUDIO pin: Standard audio pin (9Pin, 2*5Pin, 2.54mm) | ||
USB | 2*USB3.0 interface: Rear standard USB3.0 interface 2*USB2.0 interface: Rear standard USB2.0 interface 1*F_USB2 pin: Front USB2.0 pin, one set has 2*USB2.0 (9Pin, 2*5Pin, 2.54mm) 1*F_USB3 pin: Front USB2.0 pin, one set has 2*USB2.0 (9Pin, 2*5Pin, 2.54mm) | ||
Switch | 1*F_PANEL pin Switch, power light, hard disk light, restart pin (9Pin, 2*5Pin, 2.54mm) 1*AUTO_SW pin Hardware control power-on pin (3Pin, 1*3Pin, 2.0mm) | ||
Other I/O | 1*COM1 pin | Serial port, only supports RS232 (9Pin, 2*5Pin, 2.54mm) | |
1*COM2 pin | Serial port, COM2 supports RS232/RS422/RS485 optional (9Pin, 2*5Pin, 2.54mm) | ||
1*JCOM1 pin | Control COM1 pin 9 voltage 0V/5V/12V optional (6Pin, 2*3Pin, 2.0mm) | ||
1*JCOM2 pin | Control COM2 pin 9 voltage 0V/5V/12V optional (6Pin, 2*3Pin, 2.0mm) | ||
JP9/JP10/JP11 pin | COM2 supports RS422 and RS485 signal jumper settings (6Pin, 2*3Pin, 2.0mm) | ||
COM3~COM6 pins | Serial port, supports standard RS232; (39Pin, 2*20Pin, 2.0mm) | ||
1*MINI_PCIE interface | Support WIFI/3G/4G/GPS/Bluetooth modules, etc. | ||
1*SIM_CARD slot | Support SIM card, SIM card is required when using 3G/4G | ||
1*CLR_CMOS pin | Motherboard reset and discharge pin (2Pin, 1*2Pin, 2.54mm) | ||
1* J_ GPIO pin ( optional ) | GPIO control pins (10Pin, 2*5Pin, 2. 0 mm) | ||
1*SYS_FAN pin | System fan pin, full speed, does not support temperature control (3Pin, 1*3Pin, 2.54mm) | ||
1*CPU_FAN pin | CPU fan pin, supports temperature control (3Pin, 1*3Pin, 2.54mm) | ||
Operating Environment | Working temperature: -20℃~60℃; Working humidity: 5%~95% relative humidity, no condensation | ||
BIOS | AMI BIOS, supports power-on, scheduled power-on, remote power on and off, and intelligent device identification | ||
Watch Dog | Watchdog programming, support hardware reset function (256 levels, 0~255 seconds) | ||
Operating system | Supports Win10, Win8, Win7, Linux, etc. | ||
Packing & Delivery
Packaging & Shipping
Packing
Before delivery,we guarantee that every item will be tested and carefully packed with individual Anti-static bubble bag and
separated by stiff cardboards in carton boxes.
1Piece/Carton(G.W. : 1.0-1.5KG);
5Pieces/Carton(G.W. : 5.0-7.5KG);
10Pieces/Carton(G.W. : 10.0-15.0KG);
Before delivery,we guarantee that every item will be tested and carefully packed with individual Anti-static bubble bag and
separated by stiff cardboards in carton boxes.
1Piece/Carton(G.W. : 1.0-1.5KG);
5Pieces/Carton(G.W. : 5.0-7.5KG);
10Pieces/Carton(G.W. : 10.0-15.0KG);
