Hot Sale I3 3217U I3 3227U 3rd Gen I3 CPU Core I5 I7 Optional Support Linux RS485 Mini Itx Industrial PC Motherboard
Price:
$65-71 / piece
MOQ:
1 piece
Delivery Time:
Negotiable
Brand:
HH/OEM/ODM
Product Description
Product Description
Specification
HYH310 Motherboard Spec. | ||
Size | 170mm(L)*170mm(W)*22mm(H) | |
CPU | Support Intel Ivy Bridge U series Core i3-3217U, i5-3317U, i7-3517U, etc. | |
Chipset | Intel 6 series chipsets: HM65, HM67, QM67, etc. Intel 7 series chipsets: HM70, HM76, HM77, NM70, QM77, etc. | |
power supply | 1*DC_IN Supports 12V voltage input, the inner diameter of the DC head is 2.5MM The motherboard consumes about 40W when fully loaded. It is recommended to use a 12V5A or higher power supply 1*DC_PWR | |
Memory | 1*NB-DDR3 memory slot, supports 1333/1600MHz memory, supports low voltage 1.35V and standard voltage 1.5V, supports up to 8GB | |
Display | Integrated Intel HD Graphics 4000 graphics controller, supports single display, dual display copy, dual display expansion, single display under DOS 1*VGA DB15 interface: Support resolution 1920*1080@60HZ 1*VGA_H pin: Support resolution 1920*1080@60HZ (12Pin,1*12Pin,2.0mm) 1*HDMI 1.4 interface: Support resolution 1920*1080@60HZ 1*LVDS pin: Support resolution 1920*1080@60HZ (30Pin,2*15Pin,2.0mm) 1*LVDS_PWR1 pin: LVDS voltage control pin (6Pin,2*3Pin,2.54mm) 1*INVERT pin: LVDS backlight switch control pin (6Pin,1*6Pin,2.0mm) | |
Network | 1/2*LAN interface: Single network: supports Realtek 8111H Gigabit network card by default; Dual network: supports Realtek 8111H+Realtek 8111H Gigabit network card; Supports network wake-up and PXE diskless boot function 1*4G/WIFI interface: Default support for 4G/Bluetooth WiFi module The USB signal of the 4G/WIFI interface and the signal of the 2nd/4th/6th/8th/10th pin of F_USB2 are selected. By default, the 4G/WIFI interface has a USB signal. | |
Hard disk | 1*MSATA interface: Support MINI_SATA disk, support MSATA 2.0 1*SATA1 interface:Standard SATA3.0 hard disk interface, maximum transmission speed 6.0 Gbps 1*SATA2 interface: Standard SATA2.0 hard disk interface, maximum transmission speed 3.0 Gbps 2*SATA_PWR pin: Hard disk power supply pin, can take 5V, 12V powe (4Pin,1*4Pin,2.54mm) | |
Sound | Integrated Realtek ALC897 HD digital audio decoder, 6-channel high-fidelity audio controller; Can be modified to support integrated Cmedia HS-100B high-fidelity USB audio chip 1*LIN_OUT interface: Support audio output (green) 1*MIC_IN interface: Support microphone input (pink) 1*JAMP pin: Support 8 ohm 5 watt speaker output (4Pin,1*4Pin,2.0mm) | |
USB Function | 2*USB3.0 interface: Rear standard USB3.0 interface When the chipset is 6 series or HM70, HM75, the blue USB port is USB2.0 speed; When it is 7 series (HM76, HM77, NM70, QM77, etc.), the blue USB port is USB3.0 speed; 2*USB2.0 interface: Rear standard USB2.0 interface 1*F_USB1 pin: Front USB2.0 pin, one set has 2*USB2.0 (9Pin,2*5Pin,2.54mm) 1*F_USB3 pin: Front USB2.0 pin, one set has 2*USB2.0 (9Pin,2*5Pin,2.54mm) | |
Switch | 1*F_PANEL pin:Switch, power light, hard disk light, restart pin (9Pin,2*5Pin,2.54mm) 1*AUTO_SW pin:Support hardware control power on (3Pin,1*3Pin,2.0mm) | |
Other I/O | 1*COM1 pin: The serial port supports RS232 by default (9Pin,2*5Pin,2.54mm) 1*COM2 pin: Support RS232/422/485 optional, BIOS setting (9Pin,2*5Pin,2.54mm) 1*COM3~6 pin: Serial port, only supports standard RS232 (39Pin,2*20Pin,2.0mm) 1*JP1 pin: Control COM1 pin 9 voltage 0V/5V/12V optional (6Pin,2*3Pin,2.54mm) 1*JP3 pin: Control COM2 pin 9 voltage 0V/5V/12V optional (6Pin,2*3Pin,2.54mm) 1*SIM_SLOT: Support SIM card, SIM card is required when using 3G/4G 1*JLPT pin: parallel port (25Pin,2*13,2.54mm) 1*CLR_CMOS pin: Mainboard reset and discharge pins (3Pin,1*3Pin,2.54mm) 2*FAN pin: Fan pin, full speed, no temperature control (3Pin,1*3Pin,2.54mm) 1*P_GPIO pin: GPIO definable pins (12Pin,2*6Pin,2.54mm) | |
Operating Environment | Working temperature: -10℃~60℃; Working humidity: 5%~95% relative humidity, no condensation | |
BIOS | AMI BIOS, scheduled startup, remote power on/off, intelligent device identification | |
Watch Dog | Watchdog programming, support hardware reset function (256 levels, 0~255 seconds) | |
Os | Support Win10, Win8, Win7, WinXP, LINUX, etc. | |
Packing & Delivery
Packaging & Shipping
Packing
Before delivery,we guarantee that every item will be tested and carefully packed with individual Anti-static bubble bag and
separated by stiff cardboards in carton boxes.
1Piece/Carton(G.W. : 1.0-1.5KG);
5Pieces/Carton(G.W. : 5.0-7.5KG);
10Pieces/Carton(G.W. : 10.0-15.0KG);
Before delivery,we guarantee that every item will be tested and carefully packed with individual Anti-static bubble bag and
separated by stiff cardboards in carton boxes.
1Piece/Carton(G.W. : 1.0-1.5KG);
5Pieces/Carton(G.W. : 5.0-7.5KG);
10Pieces/Carton(G.W. : 10.0-15.0KG);
