2026 Hot Sale Mini ITX DDR3 Motherboard Fanless Embedded Celeron J1900 Quad Core 1.99G with LVDS 8USB 6COM
Price:
$79-87 / piece
MOQ:
1 piece
Delivery Time:
Negotiable
Brand:
HH/OEM/ODM
Product Description
Product Description
Specification
HYH310 Motherboard Spec. | ||
Size | 170mm(L)*170mm(W)*21mm(H) | |
CPU | Intel processor Celeron J1900 | |
Chip set | Intel Bay trail SOC chip set | |
Memory support | 1*NB-DDR3 SODIMM Memory slot, support 1333 / 1600 MHz memory, low voltage 1.35V, maximum support of 8GB | |
Source | 1*DC_JACK ;1*DC_PWR Support 12V voltage, the DC head inner diameter is 2.5MM The motherboard full load power consumption is about 30W.12V4A or above is recommended | |
Display function | Intel HD Graphics Graphic controller, support single display, double display replication, double display extension, single display under DOS 1*VGA DB15 interface: Support has a resolution of 1920 * 1080@60Hz 1*VGA_OUT pin: Support has a resolution of 1920 * 1080@60Hz (12Pin,1*12Pin,2.0mm) 1*HDMI 1.4 interface: Support has a resolution of 1920 * 1080@60Hz 1*HDMI_CON pin: Support has a resolution of 1920 * 1080@60Hz (16Pin,2*8Pin,2.0mm) 1*LVDS pin: Support has a resolution of 1920 * 1080@60Hz (30Pin,2*15Pin,2.0mm) 1*LVDS_PWR pin: LVDS Voltage control insert (6Pin,2*3Pin,2.0mm) 1*INVERT pin: LVDS Backlit switch control pin (6Pin,1*6Pin,2.0mm) | |
Internet function | 1/2*RJ45 LAN interface 100 million network card and gigabit network card optional, support network wake up and PXE no disk start function Gigabit: default single network Realtek 8111H, optional dual network Realtek 8111H + Realtek 8111H; Optional 100 megabytes: single network Realtek 8106E, dual network Realtek 8106E + Realtek 8106E; 1*MINI_PCIE interface: Support for WIFI / 4G / Bluetooth module | |
Hard drive function | 1*SATA interface: Standard SATA 2.0 hard disk interface 1*MSATA interface: Support for MSATA 2.0 1*SATA_PWR pin: Hard disk power supply pin, the cable power 5V, 12V. (4Pin,1*4Pin,2.54mm) | |
Sound function | Default support Realtek ALC897 HD digital audio decoder, 6-channel high-fidelity audio controller; Modiable integrated Cmedia HS-100B high-fidelity USB audio chip 1*LINE_OUT interface: Supports audio output (green) 1*MIC_IN interface: Support for microphone input (red) 1*JAMP pin: The amplifier supports 8 O 5 W horn dual channel output (4Pin,1*4Pin,2.0mm) 1*F_AUDIO pin: Standard audio insert (9Pin,2*5Pin,2.54mm) | |
USB function | 1*USB3.0 interface: Post-standard USB3.0 interface (USB3.0 under the blue group) 3*USB2.0 interface: Post-standard USB2.0 interface (USB2.0 above the blue group) 1*F_USB1 pin: Front USB2.0 pin, one group has 2 * USB2.0 (9Pin,2*5Pin,2.54mm) 1*F_USB2 pin: Front USB2.0 pin, one group has 2 * USB2.0 (9Pin,2*5Pin,2.54mm) 1*F_USB3 pin: Front USB2.0 pin, one group has 2 * USB2.0 (9Pin,2*5Pin,2.54mm) | |
Switch function | 1*F_PANEL pin: Switch, power light, hard disk light, restart pin (9Pin,2*5Pin,2.54mm) | |
Other I/O | COM1/2/5/7/8/9/10 pin: COM port,Support for the standard RS232 (9Pin,2*5Pin,2.54mm) COM3/4 pin: COM port,COM1 Support RS232 / RS422 / RS485 optional (9Pin,2*5Pin,2.54mm) COM6 pin: COM port,COM1 RS232 / RS485 optional (9Pin,2*5Pin,2.54mm) 1*JPCOM1/2/3 pin: Control COM1 / 2 / 3 pin 9th voltage 0V / 5V / 12V is optional (6Pin,2*3Pin,2.0mm) 1*JLPT pin: And port, standard print interface pin (25Pin,2*13Pin,2.0mm) 1*SIM card slot: SIM card, SIM card is required when using 4G 1*CLR_CMOS pin: Motherboard with zero clearance, discharge plug pin (3Pin,1*3Pin,2.54mm) 1*PS/2 pin: Standard PS / 2 interface pin (7Pin,1*7Pin,2.0mm) 2*FAN pin: Fan needle (3Pin,1*3Pin,2.54mm) 1*J_GPIO pin: GPIO Control the insert (10Pin,2*5Pin,2.0mm) | |
Operating environment | Operating temperature: -10℃ ~60℃; operating humidity: 5%~95% relative humidity, no condensation | |
BIOS | AMI BIOS,Support power-on, timing start, remote switch equipment intelligent identification | |
Watch Dog | Watch dog programming, hardware reset function (256 level, 0~255 seconds) | |
operating system (OS) | Supporting Win10, Win8, Win7, Linux, et al | |
Packing & Delivery
Packaging & Shipping
Packing
Before delivery,we guarantee that every item will be tested and carefully packed with individual Anti-static bubble bag and
separated by stiff cardboards in carton boxes.
1Piece/Carton(G.W. : 1.0-1.5KG);
5Pieces/Carton(G.W. : 5.0-7.5KG);
10Pieces/Carton(G.W. : 10.0-15.0KG);
Before delivery,we guarantee that every item will be tested and carefully packed with individual Anti-static bubble bag and
separated by stiff cardboards in carton boxes.
1Piece/Carton(G.W. : 1.0-1.5KG);
5Pieces/Carton(G.W. : 5.0-7.5KG);
10Pieces/Carton(G.W. : 10.0-15.0KG);
