2025 12V~19V Power EDP VGA GPIO Win 10 Linux OS Core I7 7500U 8G RAM Onboard 3.5 Inch DDR4 Motherboard
Price:
$154-159 / piece
MOQ:
1 piece
Delivery Time:
Negotiable
Brand:
HH/OEM/ODM
Product Description
Product Description
Specification
HYH310 Motherboard Spec. | ||
Form Factor | Standard 3.5inch, 146mm(L)*102mm(W)*26mm(H) | |
Processor | 6th generation Celeron 3855U,3955U,Core Skylake i3-6100U,i5-6200U,i7-6500U,etc. 7th generation Celeron 3865U,3965U,Core Kaby Lake i3-7100U,i5-7200U,i7-7500U,etc. | |
Chipset | Skylake,Kabylake high speed chipset | |
Power Supply | 1*DC_IN ; 1*4Pin ATX The inner diameter of the DC head is 2.5mm, and it supports 12V~19V wide voltage power supply by default. It can be changed to support 19V~24V wide voltage power supply; Motherboard power consumption: about 40W. It is recommended to use a power supply of 12V5A or 19V3A or above. | |
Memory | Onboard NB-DDR4 2133MHz memory,optional 4G/8G | |
Display | 6th gen: Integrated Intel HD Graphics 510/520 in CPU. 7th gen: Integrated Intel HD Graphics 610/620 in CPU. Supports single display,dual/three display copy,dual/three display expansion,single display under DOS. 1*VGA DB15 interface: Support resolution 1920*1080@60HZ 1*VGA_OUT pin: Support resolution 1920*1080@60HZ (12Pin,1*12Pin,2.0mm) 1*HDMI 1.4 interface: Support 4K resolution 4096/3840*2160@30HZ 1*EDP pin: DP-C screen cable, supports 4K resolution 4096/3840*2160@60HZ (30Pin,2*15Pin,2.0mm) | |
Network | 1/2*LAN: Dual network: default Realtek 8111H+Realtek 8111H Gigabit Ethernet card; Optional Yutaiwei YT6801+Yutaiwei YT6801 Gigabit Network Card; Single network: Realtek 8111H or Yutaiwei YT6801 Gigabit Ethernet card optional; Supports network wake-up and PXE diskless boot function. 1*Mini-PCIE interface: PCIE3.0 signal, supports WIFI/4G/Bluetooth, etc., optional support for MSATA | |
Hard Disk | 1*SATA1 interface: Standard SATA3.0 hard disk interface,its maximum transmission speed 6.0Gbps. 1*M.2 SSD: Supports Key-M interface M.2 2280 hard drive, SATA/NVME (PCIE) protocol optional When the CPU is i3/i5/i7, the motherboard NGFF supports SATA protocol by default, and to use NVME (PCIE) protocol, BIOS needs to be updated; When the CPU is 3855U/3955U/3865U/3965U, the motherboard NGFF supports NVME protocol by default and cannot change SATA protocol; | |
Sound | Integrated Cmedia HS_100B USB audio chip 1*LINE_OUT interface: Support Audio output 1*INT_SPK pin: This is the amplifier pin. It supports 8Ω 5W speaker dual channel output. (4Pin,1*4Pin,2.0mm) 1*F_AUDIO pin: Standard Audio pin (9Pin,2*5Pin,2.0mm) The F_AUDIO pin only supports MIC-IN and does not support LINE-OUT | |
USB | 2*USB3.0 interfaces: Rear standard USB3.0 interfaces 2*USB2.0 interfaces: Rear standard USB2.0 interfaces 1*F_USB1 pin: Front USB2.0 pin,one group has 2*USB2.0 (9Pin,2*5Pin,2.0mm) 1*F_USB2 pin: Front USB2.0 pin,one group has 2*USB2.0 (9Pin,2*5Pin,2.0mm) | |
Switch | 1*F_PANEL pin: Switch, power light, hard disk light, restart pin (9Pin, 2*5Pin, 2.0mm) | |
Other I/O | COM1 pin: Serial port,Supports RS232/RS422/RS485 optional, (9Pin,2*5Pin,2.0mm) COM2 pin: Serial port,Supports standard RS232. (9Pin,2*5Pin,2.0mm) COM3~6 pin: Serial port,Supports standard RS232. (40Pin,2*20Pin,2.0mm) 1*JPCOM1 pin: Control the 9th pin of the COM1 to choose optional 0V/5V/12V voltage. (6Pin,2*3Pin,2.0mm) 1*JPCOM2 pin: Control the 9th pin of the COM2 to choose optional 0V/5V/12V voltage. (6Pin,2*3Pin,2.0mm) 1*SIM slot: Support SIM card. A SIM card is required when using 4G . 1*CLR_CMOS pin: Motherboard clears,discharges pin. (2Pin,1*2Pin,2.54mm) 1*CPU FAN pin: CPU Fan pin ,does not support temperature control. (3Pin,1*3Pin,2.54mm) 1*J_GPIO pin: GPIO control pin (10Pin,2*5Pin,2.0mm) | |
Operating Environment | Operating temperature:-10℃~60℃; Working humidity:5%~95% Relative humidity, no condensation. | |
BIOS | AMI BIOS;Support power on, timed power on, and intelligent recognition of remote power on/off devices. | |
Watch Dog | Watch Dog programming supports hardware reset function (256 levels, 0~255 seconds). | |
Operating System | Support Win10,Win8,Win7 ,Linux,etc. | |
Packing & Delivery
Packaging & Shipping
Packing
Before delivery,we guarantee that every item will be tested and carefully packed with individual Anti-static bubble bag and
separated by stiff cardboards in carton boxes.
1Piece/Carton(G.W. : 1.0-1.5KG);
5Pieces/Carton(G.W. : 5.0-7.5KG);
10Pieces/Carton(G.W. : 10.0-15.0KG);
Before delivery,we guarantee that every item will be tested and carefully packed with individual Anti-static bubble bag and
separated by stiff cardboards in carton boxes.
1Piece/Carton(G.W. : 1.0-1.5KG);
5Pieces/Carton(G.W. : 5.0-7.5KG);
10Pieces/Carton(G.W. : 10.0-15.0KG);
