D38999/24wc98sn D38999 Series Jam Nut Receptacle Circular Connector
Price:
US $5-50 / Piece
MOQ:
1 PC
Delivery Time:
2-9weeks
Brand:
Dconntek
Product Description
We also offer the following products
↓ ↓
↓ ↓
| J599/24FB01SLA |
J599/24WH34SHC |
J599/24WH34SLB |
J599/24WH34SCE |
J599/24WH32PD |
| J599/24FB01SLD |
J599/24WH55PLB |
J599/24WG24SHB |
J599/24WG11PLN |
J599/24WG39SHN |
| J599/24FB99PN |
J599/24WH55PCB |
J599/24WG24SHC |
J599/24WG11PLD |
J599/24WG16SN |
| J599/24FB99PC |
J599/24WH55PCC |
J599/24WG27SCN |
J599/24WG11PCB |
J599/24WG16SA |
| J599/24FB99PHN |
J599/24WH55SLC |
J599/24WG27SCE |
J599/24WG11PLE |
J599/24WG16SB |
| J599/24WH32SB |
J599/24WH35PD |
J599/24WG27SCB | J599/24WG39SHB |
J599/24WG16SC |
| J599/24WH55PLN |
J599/24WH35PB |
J599/24WG27SCA |
J599/24WG39SHC |
J599/24WG16SD |
Can't find the product you need?
Please contact us and we will get back to you within 5 minutes
Please contact us and we will get back to you within 5 minutes
Product introduction
√ Compliance with MIL-DTL-38999M standard
√ Fast connection with three heads, with anti-loosening mechanism
√ Small size, light weight , high contact density
√ Electromagnetic shielding function
√ Crimp contacts removable , anti-oblique function
√ High-intensity vibration characteristics at high temperature, suitable for use in bad wind wet situation
√ 16# contact hole position can assemble fiber contact
√ 12#, 10#, 8# contact hole position can assemble coaxial, shield contact
√ Stainless steel shell, aluminum alloy shell and a variety of plating
![]()
![]()
√ Fast connection with three heads, with anti-loosening mechanism
√ Small size, light weight , high contact density
√ Electromagnetic shielding function
√ Crimp contacts removable , anti-oblique function
√ High-intensity vibration characteristics at high temperature, suitable for use in bad wind wet situation
√ 16# contact hole position can assemble fiber contact
√ 12#, 10#, 8# contact hole position can assemble coaxial, shield contact
√ Stainless steel shell, aluminum alloy shell and a variety of plating
Performance
MaterialShell: aluminum alloy, stainless steel, titanium alloy
Insulator: Thermoset or Thermoplastic
Grommet and seal:silicon rubber: Silicone rubber
Plating
W: Olive drab cadmium over electroless nickel base
K: Stainless steel shell, passivated
F: Electroless nickel plating
FT : Aluminum alloy satin cadmium plated
TA: Titanium alloy
Contact parts
Copper alloy surface gold-plated, crimp type, welding type and PCB type.
Durability
≥500 cycles
Vibration
Sinusoidal : 60 g, with temperature cycle and analog accessories (36 h)
Random vibration:Under high temperature, frequency 100~1000 Hz, power spectral density 1 g²/Hz, corresponding to root mean square value 41.7 g
Under ambient temperature: frequency 100~1000 Hz power spectral density 5 g²/Hz, corresponding root mean square value 49.5g
J599/24 Jam nut receptacle
| Shell no | MS Shell no |
A |
B max |
C max |
D max |
E |
F |
G screw thread |
d |
P |
| 9 | A | 16.5 | 9.9 | 3.2 | 30.5 | 22.5 | 27.1 | M12×1.0-6g | 17.70 | 17.00 |
| 11 | B | 19.2 | 9.9 | 3.2 | 35.2 | 25.7 | 32.1 | M15×1.0-6g | 20.88 | 19.53 |
| 13 | C | 23.8 | 9.9 | 3.2 | 38.4 | 30.5 | 35.0 | M18×1.0-6g | 25.58 | 24.26 |
| 15 | D | 26.9 | 9.9 | 3.2 | 41.6 | 33.6 | 38.3 | M22×1.0-6g | 28.80 | 27.53 |
| 17 | E | 30.3 | 9.9 | 3.2 | 44.8 | 36.8 | 41.8 | M25×1.0-6g | 32.01 | 30.73 |
| 19 | F | 33.4 | 9.9 | 3.2 | 49.3 | 40.0 | 46.4 | M28×1.0-6g | 35.15 | 33.86 |
| 21 | G | 36.5 | 9.9 | 3.2 | 52.7 | 43.2 | 49.6 | M31×1.0-6g | 38.28 | 37.06 |
| 23 | H | 39.7 | 9.9 | 3.2 | 55.9 | 46.3 | 52.8 | M34×1.0-6g | 41.53 | 40.26 |
| 25 | J | 42.8 | 9.9 | 3.2 | 59.0 | 51.0 | 55.8 | M37×1.0-6g | 44.68 | 43.41 |
FAQ
Q: What is your terms of payment?
A: We accept T/T(Wire transfer), Western Union and Paypal. RMB also OK
Q: Could I have the price list?
A: We do not have a price list of all of our products.The price are always changing because of the material cost.If you want to check any price of our products,please feel free to contact us.
A: We do not have a price list of all of our products.The price are always changing because of the material cost.If you want to check any price of our products,please feel free to contact us.
Q: Can you produce according to the samples?
A: We have customized products for many customers. After receiving the deposit, we will produce the products according to the requirements within 30-60 days. But the specific time depends on the specifications and quantity of the samples.
A: We have customized products for many customers. After receiving the deposit, we will produce the products according to the requirements within 30-60 days. But the specific time depends on the specifications and quantity of the samples.
Q: Can you provide samples ?
A: we provide free samples for test (shipping cost is not free)
![]()
![]()
![]()
![]()
A: we provide free samples for test (shipping cost is not free)
Q: What's the delivery time?
A: It depends on the quantity.It usually takes 3-5 days for small quantity.
