PP Strap Production Line Single Screw Designed for Continuous Plastic Strap Extrusion and Durable Packaging Applications
This regular PP strap extrusion production line is a fully automatic single-screw continuous extrusion system dedicated to manufacturing high-tensile polypropylene packing straps. Adopted widely in packaging, logistics transportation and industrial bundling scenarios, this line delivers highly uniform strap dimension and stable finished product quality.
Equipped with a customized single screw and barrel structure, the extruder achieves excellent plasticization effect for PP raw materials. The complete line consists of automatic feeding system, extrusion die head, water cooling tank, drying unit, preheating & stretching mechanism, embossing device and multiple automatic winding machines. The whole production line is centrally synchronized and controlled by PLC touch screen system, which ensures stable running and high production efficiency.
It supports processing both virgin PP pellets and recycled reprocessed PP granules, with color masterbatch available for customized color production. The finished packing strap width ranges from 5mm to 19mm, thickness adjustable between 0.3mm and 1.3mm, which meets diversified bundling demands across multiple industries.
| Model | Screw Dia. (mm) | Strap No. | Capacity (Kg/hr) | Strap Width (mm) | Strap Thickness (mm) |
|---|---|---|---|---|---|
| ZRPP-100A | 100 | 2~4 | 70~160 | 5~19 | 0.3~1.3 |
- Fully automatic single-screw extrusion forming production line
- Optimized screw & barrel design for superior melting and plasticization of PP material
- PLC intelligent linkage control for synchronous operation of all sections
- Compatible with virgin PP material, recycled PP granules and color masterbatch
- Integrated full-process configuration: Feeding → Extrusion → Cooling → Drying → Stretching → Embossing → Automatic Winding
- Supports simultaneous production of 2 to 4 straps in one run, high output efficiency
- Adjustable strap width & thickness, flexible switching between different product specifications
- Low failure rate, easy operation and daily maintenance
- Feeder: Automatic feeding for raw materials including recycled pellets, virgin granules and masterbatch
- Extruder & Die Head: Core extrusion unit to melt PP material and extrude initial strap shape
- Water Cooling Tank: Rapid cooling to shape the extruded strap
- Preheating & Stretching Unit: Stretch the strap to enhance tensile strength
- Embossing Machine: Press anti-slip texture on strap surface
- PLC Control Cabinet: Central parameter setting and whole-line operation monitoring
- Automatic Winder: Wind finished straps into standard rolls automatically
- Carton & corrugated box sealing and packaging
- Steel coil, metal parts and hardware product bundling
- Timber, lumber and wooden board packing & strapping
- Pallet cargo fixation for warehouse and logistics
- Textile bale, cotton and fabric bundle packaging
- Building materials, plastic pipes and profile binding
- General warehousing, freight and distribution packaging operations
We provide one-stop comprehensive after-sales service for global clients:
- On-site equipment installation guidance and machine commissioning
- Professional operation & maintenance training for your operators
- Long-term stable supply of original spare parts at preferential price
- Remote online technical troubleshooting and real-time technical consultation
- Customized production layout and process plan according to your factory conditions
