Steel Galvanised Pneumatic Air Cylinders Rod Clevis SG-M20X1 5 6147 GTIN4052568001117
FESTO Rod clevis SG-M20X1,5 6147 GTIN 4052568001117 Pneumatic Air Cylinders
About product
1.Metal material
2.High hardness, abrasion resistance and compression resistance, suitable for high frequency operation
3.The best partner of the cylinder
4.Low corrosion stress
5. Dry indoor application or transport and storage protection. Also applies to parts behind covers, in the non-visible interior area, and parts which are covered in the application (e.g. drive trunnions).
Product Technical Data
| Size | M20x1.5 |
| Conforms to standard | ISO 8140 |
| Threaded connection | Female thread M20x1.5 |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Suitability for the production of Li-ion batteries | Metals with more than 1% copper by mass are excluded from use. Exceptions are printed circuit boards, cables, electrical plug connectors and coils |
| Ambient temperature | -40°C-150°C |
| Product weight | 793 g |
| Note on materials | RoHS-compliant |
| Material bolt | Steel Galvanised |
| Material clevis | Steel Galvanised |
| Material nut | Steel Galvanised |
Another size as follow
| Type | Part no. | Weight(g) | GTIN | Price |
| SG-M20x1.5 | 6147 | 793 | 4052568001117 | USD30-40 |
| SG-M27x2-B | 14987 | 2135 | 4052568112677 | USD100-150 |
| SG-M36x2 | 9581 | 4320 | 4052568001940 | USD150-200 |
| SG-M42x2 | 9582 | 7520 | 4052568111502 | USD350-400 |
| SG-M48x2 | 9583 | 10029 | 4052568111519 | USD650-700 |
Rod clevis SG
Scope of delivery: 1 rod clevis, 1 bolt, 1 retaining ring, 1 hex nut (DIN 439).
Material: Galvanised steel Free of copper and PTFE RoHS-compliant.
Attention
1,Before you endorse the parcel, please do open the package, and check out whether the items are damaged during the shipping process.
If so, please do refuse to sign for the parcel, the courier will send back the package to our company. Otherwise we are not responsible for this...
2,Any order is welcome; we will give discounts and combined shipping costs for you if you order more or mix order. If you have any questions,
please feel free to contact us.
There are many specifications of connectors, price and delivery time. Welcome to inquire.
