DYSC-7-5-Y1F 548012 Pneumatic Air Cylinders Shock Absorber GTIN4052568005986

Name: DYSC-7-5-Y1F 548012 Pneumatic Air Cylinders Shock Absorber GTIN4052568005986
Brand: Airwolf Automation

Price Negotiable

Price: USD60-70

MOQ: 1pc

Delivery Time: 7-10 working days

Brand: FESTO

Product Description

FESTO Shock absorber DYSC-7-5-Y1F 548012 GTIN4052568005986 Pneumatic Air Cylinders

Shock absorber DYSC

1.Universal screw-in hydraulic shock absorber.

2.Rapidly increasing cushioning force path thanks to path-controlled flow control function.

3.Short cushioning stroke.
4.Hydraulic shock absorber with path-controlled flow control function.

5.Suitable for rotary drives.

6.With metal fixed stop.

7.Hydraulic shock absorber with path-controlled flow control function.

Technical Data

Size	7
Stroke	5 mm
Cushioning	Self-adjusting
Mounting position	optional
Position detection	Without
Symbol	00991497
Max. impact speed	3 m/s
Reset time at room temperature	0.2 s
Reset time at min. ambient temperature1	1s
Mode of operation	Single-acting Pushing
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B2-L
Ambient temperature	-10°C-80°C
Cushioning length	5 mm
Max. stop force	300 N
Max. energy consumption per stroke	2 J
Max. energy consumption per hour	12000 J
Max. residual energy	0.01 J
Reset force	1.2 N
Product weight	17 g
Type of mounting	Via lock nut
Note on materials	RoHS-compliant
Material seals	NBR
Material housing	High-alloy steel
Material piston rod	High-alloy steel
