GTIN4052568108441 1908263 16mm Pneumatic Air Cylinders DSNU-16-60-P-A ISO
Price:
EXW USD25-30
MOQ:
1pc
Delivery Time:
7-10 working days
Brand:
FESTO
Product Description
FESTO ISO cylinder DSNU-16-60-P-A 1908263 GTIN4052568108441 Pneumatic Air Cylinders
About product
1.A variety of cylinder mounting accessories are available and flexible.
2.It is fully equipped, such as the trunnion on the end cover, to deal with various emergencies.
3.Simple, fast, space saving and tamper proof.
4.Long service life.
5.Easy to install in narrow space.
Technical Data
| Stroke | 60 mm |
| Piston diameter | 16 mm |
| Piston rod thread | M6 |
| Cushioning | rings/plates at both ends |
| Mounting position | optional |
| Conforms to standard | CETOP RP 52 P ISO 6432 |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Cylinder barrel |
| Position detection | Via proximity switch |
| Symbol | 00991217 |
| Variants | Piston rod at one end |
| Mode of operation | Double-acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom class | Class 6 according to ISO 14644-1 |
| Ambient temperature | -20°C-80°C |
| Impact energy in end positions | 0.15 J |
| Basic weight for 0 mm stroke | 89.9 g |
| Additional weight per 10 mm stroke | 4.6 g |
| Type of mounting | With accessories |
| Pneumatic connection | M5 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy Colourless anodised |
| Material seals | NBR TPE-U(PU) |
| Material piston rod | High-alloy stainless steel |
| Material cylinder barrel | High-alloy stainless steel |
Other stroke as Below
| Type | Order no | GTIN | Price |
| DSNU-16-10-P-A | 19198 | 4052568003104 | USD25-30 |
| DSNU-16-15-P-A | 1908259 | 4052568108403 | USD25-30 |
| DSNU-16-20-P-A | 1908260 | 4052568108410 | USD25-30 |
| DSNU-16-25-P-A | 19199 | 4052568003111 | USD25-30 |
| DSNU-16-30-P-A | 1908261 | 4052568108427 | USD25-30 |
| DSNU-16-35-P-A | 1908262 | 4052568108434 | USD25-30 |
| DSNU-16-40-P-A | 19200 | 4052568067007 | USD25-30 |
| DSNU-16-50-P-A | 19201 | 4052568003128 | USD25-30 |
| DSNU-16-60-P-A | 1908263 | 4052568108441 | USD25-30 |
| DSNU-16-70-P-A | 1908264 | 4052568108458 | USD25-30 |
| DSNU-16-80-P-A | 19202 | 4052568067014 | USD25-30 |
| DSNU-16-100-P-A | 19203 | 4052568003135 | USD25-30 |
| DSNU-16-125-P-A | 19204 | 4052568003142 | USD25-30 |
| DSNU-16-150-P-A | 1908265 | 4052568108465 | USD25-30 |
| DSNU-16-160-P-A | 19205 | 4052568067021 | USD25-30 |
| DSNU-16-200-P-A | 19206 | 4052568003159 | USD25-30 |
Max. transverse load Fq as a function of projection l
FESTO's profile cylinder and pull rod cylinder are standard cylinders conforming to ISO15552 With self-adjusting throttle terminal position buffer.
There are so many type ,please call me immediately!
