DSNU-20-100-P-A 19212 Pneumatic Air Cylinders ISO GTIN4052568009427
Price:
EXW USD40-50
MOQ:
1pc
Delivery Time:
7-10 working days
Brand:
FESTO
Product Description
FESTO ISO cylinder DSNU-20-100-P-A 19212 GTIN4052568009427 Pneumatic Air Cylinders
About product
1.Stainless steel piston rod.
2.Good running performance and long service life.
3.Extensive range of accessories makes it possible to install the cylinder virtually anywhere.
4.Piston rod with male thread.
5.Cylinder barrel made of stainless steel.
6.Bearing and end caps made of wrought aluminium alloy.
Technical Data
|
Stroke
|
100 mm |
| Piston diameter | 20 mm |
| Piston rod thread | M8 |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Conforms to standard | CETOP RP 52 P ISO 6432 |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Cylinder barrel |
| Position detection | Via proximity switch |
| Symbol | 00991217 |
| Variants | Piston rod at one end |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom class | Class 6 according to ISO 14644-1 |
| Ambient temperature | -20°C-80°C |
| Impact energy in end positions | 0.2 J |
| Basic weight for 0 mm stroke | 186.8 g |
| Additional weight per 10 mm stroke | 7.2 g |
| Type of mounting | With accessories |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy Colourless anodised |
| Material seals | NBR TPE-U(PU) |
| Material piston rod | High-alloy stainless steel |
| Material cylinder barrel | High-alloy stainless steel |
Other stroke as Below
| Type | Order no | GTIN | Price |
| DSNU-20-10-P-A | 19207 | 4052568003166 | USD40-50 |
| DSNU-20-15-P-A | 1908282 | 4052568108632 | USD40-50 |
| DSNU-20-20-P-A | 1908283 | 4052568108649 | USD40-50 |
| DSNU-20-25-P-A | 19208 | 4052568003173 | USD40-50 |
| DSNU-20-30-P-A | 1908284 | 4052568108656 | USD40-50 |
| DSNU-20-35-P-A | 1908285 | 4052568108663 | USD40-50 |
| DSNU-20-40-P-A | 19209 | 4052568003180 | USD40-50 |
| DSNU-20-50-P-A | 19210 | 4052568003197 | USD40-50 |
| DSNU-20-60-P-A | 1908286 | 4052568108670 | USD40-50 |
| DSNU-20-70-P-A | 1908287 | 4052568108687 | USD40-50 |
| DSNU-20-80-P-A | 19211 | 4052568003203 | USD40-50 |
| DSNU-20-100-P-A | 19212 | 4052568009427 | USD40-50 |
| DSNU-20-125-P-A | 19213 | 4052568003210 | USD40-50 |
| DSNU-20-150-P-A | 1908288 | 4052568108694 | USD40-50 |
| DSNU-20-160-P-A | 19214 | 4052568067038 | USD40-50 |
| DSNU-20-200-P-A | 19215 | 4052568067045 | USD40-50 |
| DSNU-20-250-P-A | 19216 | 4052568009434 | USD40-50 |
| DSNU-20-300-P-A | 19217 | 4052568003227 | USD40-50 |
| DSNU-20-320-P-A | 34718 | 4052568068066 | USD40-50 |
Product detail
| Cushioning types | Cushioning P |
| Mode of operation | The drive has elastic polymer flexible end-position cushioning |
| Application | Small loads |
| Low speeds | |
| Low impact energies | |
| Advantages | No adjustment required |
| Saves tim |
Peripherals overview
There are so many type ,please call me immediately!
