ISO Pneumatic Air Cylinders DSBC-80-300-PPVA-N3 2126600 GTIN4052568252076
Price:
EXW USD140-150
MOQ:
1pc
Delivery Time:
10-15 working days
Brand:
FESTO
Product Description
FESTO ISO cylinder DSBC-80-300-PPVA-N3 2126600 GTIN4052568252076 Pneumatic Air Cylinders
Advantage
1.With protection against rotation.
2.Low friction.
3.Constant, slow movement.
4.Low friction for balancer applications.
Technical Data
| Stroke | 300mm |
| Piston diameter | 80mm |
| Piston rod thread | M20x1.5 |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | optional |
| Conforms to standard | ISO 15552 |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Symbol | 00991235 |
| Variants | Piston rod at one end |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Cushioning length | 31mm |
| Basic weight for 0 mm stroke | 2660 g |
| Additional weight per 10 mm stroke | 92 g |
| Type of mounting | Via female thread With accessories Either: |
| Pneumatic connection | G3/8 |
| Note on materials | RoHS-compliant |
| Material cover | Die-cast aluminium, coated |
| Material piston seal | TPE-U(PU) |
| Material piston | Wrought aluminium alloy |
| Material piston rod | High-alloy steel |
| Material piston rod wiper | TPE-U(PU) |
| Buffer seal material | TPE-U(PU) |
| Cushioning piston material | POM |
| Material cylinder barrel | Smooth-anodised wrought aluminium alloy |
| Material nut | Galvanised steel |
| Material bearing | POM |
| Material collar screws | Galvanised steel |
Other size as below
| Type | Order no | Weight(g) | Price |
| DSBC-80-20-PPVA-N3 | 2126594 | 2844 | USD140-150 |
| DSBC-80-25-PPVA-N3 | 1383333 | 2890 | USD140-150 |
| DSBC-80-30-PPVA-N3 | 2126595 | 2936 | USD140-150 |
| DSBC-80-40-PPVA-N3 | 1383334 | 3028 | USD140-150 |
| DSBC-80-50-PPVA-N3 | 1383335 | 3120 | USD140-150 |
| DSBC-80-60-PPVA-N3 | 2126597 | 3212 | USD140-150 |
| DSBC-80-70-PPVA-N3 | 2126598 | 3304 | USD140-150 |
| DSBC-80-80-PPVA-N3 | 1383336 | 3396 | USD140-150 |
| DSBC-80-100-PPVA-N3 | 1383337 | 3580 | USD140-150 |
| DSBC-80-125-PPVA-N3 | 1383338 | 3810 | USD140-150 |
| DSBC-80-150-PPVA-N3 | 2126599 | 4040 | USD140-150 |
| DSBC-80-160-PPVA-N3 | 1383339 | 4132 | USD140-150 |
| DSBC-80-200-PPVA-N3 | 1383340 | 4500 | USD140-150 |
| DSBC-80-250-PPVA-N3 | 1383341 | 4960 | USD140-150 |
| DSBC-80-300-PPVA-N3 | 2126600 | 5420 | USD140-150 |
| DSBC-80-320-PPVA-N3 | 1383342 | 5604 | USD140-150 |
| DSBC-80-400-PPVA-N3 | 1383343 | 6340 | USD140-150 |
| DSBC-80-500-PPVA-N3 | 1383344 | 7260 | USD140-150 |
Dimensions
There are so many kinds. Hurry to call me!
