Aluminium Anodised Compact Pneumatic Air Cylinders ADNGF-32-30-P-A 554243
Price:
EXW USD50-60
MOQ:
1pc
Delivery Time:
10-15working days
Brand:
FESTO
Product Description
FESTO Compact cylinder ADNGF-32-30-P-A 554243 GTIN4052568198695 Pneumatic Air Cylinders
About product
1.Compact cylinder, double-acting, standard hole pattern.
2.Elastic cushioning rings/plates on both sides.
3.Compact cylinder saves more space.
Technical Data
| Stroke | 30 mm |
| Piston diameter | 32 mm |
| Based on standard | ISO 21287 |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Protection against torque/guide | Guide rod with yoke |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Basic weight for 0 mm stroke | 327 g |
| Additional weight per 10 mm stroke | 38 g |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material cover | Aluminium Anodised |
| Material seals | TPE-U(PUR) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Wrought aluminium alloy Smooth anodised |
Other size as below
| Type | Order no | Weight(g) | Price |
| ADNGF-32-5-P-A | 554238 | 346 | USD50-60 |
| ADNGF-32-10-P-A | 554239 | 365 | USD50-60 |
| ADNGF-32-15-P-A | 554240 | 384 | USD50-60 |
| ADNGF-32-20-P-A | 554241 | 403 | USD50-60 |
| ADNGF-32-25-P-A | 554242 | 422 | USD50-60 |
| ADNGF-32-30-P-A | 554243 | 441 | USD50-60 |
| ADNGF-32-40-P-A | 554244 | 479 | USD50-60 |
| ADNGF-32-50-P-A | 554245 | 517 | USD50-60 |
| ADNGF-32-60-P-A | 554246 | 555 | USD50-60 |
| ADNGF-32-80-P-A | 554247 | 631 | USD50-60 |
Materials
