Compact Pneumatic Air Cylinders ADNGF-40-50-P-A 554255 GTIN4052568198800
Price:
EXW USD60-80
MOQ:
1pc
Delivery Time:
10-15working days
Brand:
FESTO
Product Description
FESTO Compact cylinder ADNGF-40-50-P-A 554255 GTIN4052568198800 Pneumatic Air Cylinders
About product
1.Time-saving,No adjustment required.
2.Small cushioning capacity ,Low speeds, Small loads.
3.The drive has elastic polymer flexible end-position cushioning.
4.Cushioning P.
Technical Data
| Stroke | 50 mm |
| Piston diameter | 40 mm |
| Based on standard | ISO 21287 |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Protection against torque/guide | Guide rod with yoke |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Basic weight for 0 mm stroke | 430 g |
| Additional weight per 10 mm stroke | 45 g |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material cover | Aluminium Anodised |
| Material seals | TPE-U(PUR) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Wrought aluminium alloy Smooth anodised |
Other size as below
| Type | Order no | Weight(g) | Price |
| ADNGF-40-5-P-A | 554248 | 453 | USD60-80 |
| ADNGF-40-10-P-A | 554249 | 475 | USD60-80 |
| ADNGF-40-15-P-A | 554250 | 498 | USD60-80 |
| ADNGF-40-20-P-A | 554251 | 520 | USD60-80 |
| ADNGF-40-25-P-A | 554252 | 543 | USD60-80 |
| ADNGF-40-30-P-A | 554253 | 565 | USD60-80 |
| ADNGF-40-40-P-A | 554254 | 610 | USD60-80 |
| ADNGF-40-50-P-A | 554255 | 655 | USD60-80 |
| ADNGF-40-60-P-A | 554256 | 700 | USD60-80 |
| ADNGF-40-80-P-A | 554257 | 790 | USD60-80 |
Type codes
A wide range of products with excellent prices. Please hurry to me!
