Compact Pneumatic Air Cylinders ADNGF-80-20-P-A 554279 GTIN4052568199043
Price:
EXW USD150-200
MOQ:
1pc
Delivery Time:
10-15working days
Brand:
FESTO
Product Description
FESTO Compact cylinder ADNGF-80-20-P-A 554279 GTIN4052568199043 Pneumatic Air Cylinders
Advantage
1.Low requirements for users.
2.Large output force.
3.Strong adaptability.
Technical Data
| Stroke | 20 mm |
| Piston diameter | 80mm |
| Based on standard | ISO 21287 |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Protection against torque/guide | Guide rod with yoke |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Basic weight for 0 mm stroke | 1468 g |
| Additional weight per 10 mm stroke | 97 g |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material cover | Aluminium Anodised |
| Material seals | TPE-U(PUR) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Wrought aluminium alloy Smooth anodised |
Other size as follow:
| Type | Order no | Weight(g) | Price |
| ADNGF-80-10-P-A | 554277 | 1565 | USD150-200 |
| ADNGF-80-15-P-A | 554278 | 1613 | USD150-200 |
| ADNGF-80-20-P-A | 554279 | 1662 | USD150-200 |
| ADNGF-80-25-P-A | 554280 | 1711 | USD150-200 |
| ADNGF-80-30-P-A | 554281 | 1759 | USD150-200 |
| ADNGF-80-40-P-A | 554282 | 1856 | USD150-200 |
| ADNGF-80-50-P-A | 554283 | 1953 | USD150-200 |
| ADNGF-80-60-P-A | 554284 | 2050 | USD150-200 |
| ADNGF-80-80-P-A | 554285 | 2244 | USD150-200 |
Dimensions – Basic version
FESTO cylinder is safe to use, simple in system, various in models and widely used.
A wide range of products with excellent prices. Please hurry to me!
