Guided Drive DFM-20-30-P-A-GF Pneumatic Air Cylinders 170842 GTIN4052568139674
Price:
EXW USD80-100
MOQ:
1pc
Delivery Time:
10-15working days
Brand:
FESTO
Product Description
FESTO Guided drive DFM-20-30-P-A-GF 170842 GTIN4052568139674 Pneumatic Air Cylinders
About Product
1.High rigidity,Maintenance-free.
2.Elastic cushioning rings/plates at both ends.
3.Excellent protection against torsion, high resistance to torques and transverse loads.
Technical Data
| Stroke | 30 mm |
| Piston diameter | 20 mm |
| Operating mode, drive unit | Yoke |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Guide | Plain-bearing guide |
| Design | Guidance |
| Position detection | Via proximity switch |
| Symbol | 00991737 |
| Max. speed | 0.8 m/s |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Product weight | 850 g |
| Pneumatic connection | M5 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | NBR |
| Material housing | Wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
Other size as follow
| Type | Order no | Weight(g) | Price |
| DFM-20-20-P-A-GF | 170840 | 769 | USD80-100 |
| DFM-20-25-P-A-GF | 170841 | 806 | USD80-100 |
| DFM-20-30-P-A-GF | 170842 | 850 | USD80-100 |
| DFM-20-40-P-A-GF | 170843 | 1070 | USD80-100 |
| DFM-20-50-P-A-GF | 170844 | 1158 | USD80-100 |
| DFM-20-80-P-A-GF | 170845 | 1422 | USD80-100 |
| DFM-20-100-P-A-GF | 170846 | 1592 | USD80-100 |
Use as a stopper cylinder
A wide range of products with excellent prices. Please hurry to me!
