GTIN4052568013196 Pneumatic Air Cylinders Guided Drive DFM-25-100-P-A-GF 170853
Price:
EXW USD100-120
MOQ:
1pc
Delivery Time:
7-10working days
Brand:
FESTO
Product Description
FESTO Guided drive DFM-25-100-P-A-GF 170853 GTIN4052568013196 Pneumatic Air Cylinders
About Product
1.Sturdy and precise.
2.High resistance to torques and transverse loads.
3.Drive and guide unit in a single housing.
Technical Data
| Stroke | 100 mm |
| Piston diameter | 25 mm |
| Operating mode, drive unit | Yoke |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Guide | Plain-bearing guide |
| Design | Guidance |
| Position detection | Via proximity switch |
| Symbol | 00991737 |
| Max. speed | 0.8 m/s |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Product weight | 2225 g |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | NBR |
| Material housing | Wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
Other size as follow
| Type | Order no | Weight(g) | Price |
| DFM-25-20-P-A-GF | 170847 | 1256 | USD100-120 |
| DFM-25-25-P-A-GF | 170848 | 1308 | USD100-120 |
| DFM-25-30-P-A-GF | 170849 | 1368 | USD100-120 |
| DFM-25-40-P-A-GF | 170850 | 1515 | USD100-120 |
| DFM-25-50-P-A-GF | 170851 | 1635 | USD100-120 |
| DFM-25-80-P-A-GF | 170852 | 1993 | USD100-120 |
| DFM-25-100-P-A-GF | 170853 | 2225 | USD100-120 |
Extremely functional
A wide range of products with excellent prices. Please hurry to me!
