GTIN4052568446710 Mini Slide Air Pneumatic Cylinder DGST-10-20-E1A 8078840
Price:
EXW USD350-400
MOQ:
1pc
Delivery Time:
10-15working days
Brand:
FESTO
Product Description
FESTO Mini slide DGST-10-20-E1A 8078840 GTIN4052568446710 Pneumatic Air Cylinders
About Product
1.Excellent value for money.
2.High feed forces.
3.Symmetrical mounting interfaces.
4.Precise and resilient roller bearing guide.
5.Simple design with symmetrical mounting interfaces.
6.Can be operated without additional cushioning components.
Technical Data
| Stroke | 20 mm |
| Piston diameter | 10 mm |
| Operating mode, drive unit | Yoke |
| Cushioning | Elastomer cushioning, double-sided, stroke not adjustable |
| Mounting position | optional |
| Guide | Recirculating ball bearing guide |
| Design | Twin piston Yoke Piston rod Slide |
| Position detection | Via proximity switch |
| Symbol | 00991249 |
| Max. speed | 0.5 m/s |
| Repetition accuracy | <= 0.3 mm |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10°C-60°C |
| Product weight | 254 g |
| Type of mounting | With through-hole |
| Pneumatic connection | M5 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | HNBR |
| Material guide | POM TPE-E High-alloy steel |
| Material housing | Wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
Other size as follow
| Type | Order no | Weight(g) | Price |
| DGST-10-10-E1A | 8078839 | 247 | USD350-400 |
| DGST-10-20-E1A | 8078840 | 254 | USD350-400 |
| DGST-10-30-E1A | 8078841 | 292 | USD350-400 |
| DGST-10-40-E1A | 8078842 | 324 | USD350-400 |
| DGST-10-50-E1A | 8078843 | 359 | USD350-400 |
| DGST-10-80-E1A | 8078844 | 501 | USD350-400 |
| DGST-10-100-E1A | 8078845 | 561 | USD350-400 |
Application examples
A wide range of products with excellent prices. Please hurry to me!
