Mini Slide Pneumatic Air Cylinders DGST-16-80-E1A 8078858 GTIN4052568446895

Price Negotiable

Price: EXW USD450-500

MOQ: 1pc

Delivery Time: 10-15working days

Brand: FESTO

Product Description

FESTO Mini slide Mini slide DGST-16-80-E1A 8078858 GTIN4052568446895 Pneumatic Air Cylinders

Advantage

1.Elastomer cushioning, at both ends, stroke not adjustable .

2.Enhanced precision.

3.Longer service life.

4.Space-saving mounting of mini-slides next to one another.

5.The connection kit enables having axial supply ports.

6.Particularly suitable for applications in which no space is available at the side for supply ports.

Technical Data

Stroke	80 mm
Piston diameter	16 mm
Operating mode, drive unit	Yoke
Cushioning	Elastomer cushioning, double-sided, stroke not adjustable
Mounting position	optional
Guide	Recirculating ball bearing guide
Design	Twin piston Yoke Piston rod Slide
Position detection	Via proximity switch
Symbol	00991249
Max. speed	0.5 m/s
Repetition accuracy	<= 0.3 mm
Mode of operation	Double-acting
Corrosion resistance class CRC	1 - Low corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-10°C-60°C
Product weight	930 g
Type of mounting	With through-hole
Pneumatic connection	M5
Note on materials	RoHS-compliant
Material cover	Wrought aluminium alloy
Material seals	HNBR
Material guide	POM TPE-E High-alloy steel
Material housing	Wrought aluminium alloy
Material piston rod	High-alloy stainless steel

Other size as follow
