MVH-5-1/8-B Monostable Pneumatic Solenoid Valves 19779 GTIN4052568113476
Price:
EXW USD80-100
MOQ:
1pc
Delivery Time:
7-10 working days
Brand:
FESTO
Product Description
FESTO Solenoid valve MVH-5-1/8-B 19779 GTIN4052568113476 Pneumatic Solenoid Valves
About product
1.electrical actuation.
2.Functional and timeless design, enclosed front housing.
3.Poppet valve for monostable functions or piston spool for more complex versions with air spring.
Technical Data
| Valve function | 5/2-way, monostable |
| Type of actuation | Electric |
| Construction width | 26 mm |
| Standard nominal flow rate | 750 l/min |
| pneumatic working port | G1/8 |
| Operating voltage | 24V DC |
| Design | Poppet seat |
| Type of reset | Mechanical spring |
| Nominal size | 5 mm |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | Internal |
| Flow direction | Non-reversible |
| Symbol | 00991035 |
| lap | Underlap |
| b value | 0.34 |
| C value | 3 l/sbar |
| Max. switching frequency | 3 Hz |
| Switching time off | 36 ms |
| Switching time on | 20 ms |
| Characteristic coil data | 24 V DC: 2.5 W |
| Permissible voltage fluctuations | +/- 10 % |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Storage temperature | -40°C-60°C |
| Media temperature | -5°C-50°C |
| Ambient temperature | -5°C-50°C |
| Product weight | 230 g |
| Type of mounting | On PR rail With through-hole Either: |
| Pilot exhaust port 84 | M5 |
| Pneumatic connection, port 1 | G1/8 |
| Pneumatic connection, port 2 | G1/8 |
| Pneumatic connection, port 3 | G1/8 |
| Pneumatic connection, port 4 | G1/8 |
| Pneumatic connection, port 5 | G1/8 |
| Note on materials | RoHS-compliant |
| Material seals | NBR TPE-U(PU) |
| Material housing | Die-cast aluminium |
Another Size as below,
| Type | Order no | Price |
| MVH-5-1/8-L-B | 19749 | USD80-100 |
| MVH-5-1/4-L-B | 31009 | USD80-100 |
| MVH-5-3/8-L-B | 14947 | USD80-100 |
| MVH-5-1/8-L-S-B | 19750 | USD80-100 |
| MVH-5-1/4-L-S-B | 33184 | USD80-100 |
| MVH-5-3/8-L-S-B | 33180 | USD80-100 |
| MVH-5-1/8-B | 19779 | USD80-100 |
| MVH-5-1/4-B | 15701 | USD80-100 |
| MVH-5-3/8-B | 19945 | USD80-100 |
| MVH-5-1/8-S-B | 30996 | USD80-100 |
| MVH-5-1/4-S-B | 15903 | USD80-100 |
| MVH-5-3/8-S-B | 15342 | USD80-100 |
Sectional view
There are so many products, welcome to enquire!
