Wrought Aluminium Alloy Pneumatic Solenoid Valves 8042571

Price Negotiable

Price: EXW USD50-60

MOQ: 1pc

Delivery Time: 7-10 working days

Brand: FESTO

Product Description

FESTO Solenoid valve VUVG-BK14-M52-AT-F-1H2L-S 8042571 GTIN4052568286965 Pneumatic Solenoid Valves

About product
1.High flow rate relative to its size.

2.Compact universal valve.

3.Connection technology via electrical connection box (E-box).

4.Internal pilot air supply.

5.Pneumatic spring return.

Technical Data

Valve function	5/2-way, monostable
Type of actuation	Electric
Valve size	14 mm
Standard nominal flow rate	380 l/min
pneumatic working port	Flange
Operating voltage	24V DC
Design	Piston slide with sealing ring
Type of reset	Pneumatic spring
Approval	c UL us - Recognized (OL)
Certificate issuing authority	UL MH19482
Degree of protection	IP40
Exhaust-air function	With flow control option
Sealing principle	Soft
Mounting position	optional
Manual override	Detenting Non-detenting
Type of piloting	Pilot actuated
Pilot air supply	Internal
Flow direction	Non-reversible
Symbol	00992908
lap	Positive overlap
Signal status display	LED
Max. switching frequency	2 Hz
Switching time off	24 ms
Switching time on	14 ms
Duty cycle	100%
Characteristic coil data	24 V DC: 0.8 W
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC	0 - No corrosion stress
LABS (PWIS) conformity	VDMA24364 zone III
Media temperature	-5°C-50°C
Pilot medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Ambient temperature	-5°C-50°C
Product weight	65 g
Electrical connection	2-pin Plug pattern H, horizontal connection Plugs
Type of mounting	On manifold rail With through-hole
Pneumatic connection, port 2	Flange
Pneumatic connection, port 4	Flange
Note on materials	RoHS-compliant
Material seals	HNBR NBR
Material housing	Wrought aluminium alloy
