VUVG-L14-M52-AT-G18-1P3 Festo Solenoid Valve 566499 GTIN4052568100209

Name: VUVG-L14-M52-AT-G18-1P3 Festo Solenoid Valve 566499 GTIN4052568100209
Brand: Airwolf Automation

Price Negotiable

Price: EXW USD50-60

MOQ: 1pc

Delivery Time: 7-10 working days

Brand: FESTO

Product Description

FESTO Solenoid valve VUVG-L14-M52-AT-G18-1P3 566499 GTIN4052568100209 Pneumatic Solenoid Valves

About product

1.Pneumatic spring return.

2.Internal pilot air supply.

3.Sturdy and durable metal components.

4.Choice of quick push-in connectors.

5.Piston spool with sealing cartridge (VUVG-L, VUVG-B).

Technical Data

Valve function	5/2-way, monostable
Type of actuation	Electric
Valve size	14 mm
Standard nominal flow rate	700 l/min ... 780 l/min
pneumatic working port	G1/8
Operating voltage	24V DC
Design	Piston gate valve
Type of reset	Pneumatic spring
Approval	RCM trademark c UL us - Recognized (OL)
Degree of protection	IP40 IP65 With plug socket
Nominal size	5.6 mm
Exhaust-air function	With flow control option
Sealing principle	Soft
Mounting position	optional
Manual override	Detenting Non-detenting Covered
Type of piloting	Pilot actuated
Pilot air supply	Internal
Symbol	00992908
lap	Positive overlap
Suitability for vacuum	no
Switching time off	22 ms
Switching time on	14 ms
Duty cycle	100%
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Media temperature	-5°C-60°C
Ambient temperature	-5°C-60°C
Product weight	78 g
Electrical connection	Via electrical sub-base
Type of mounting	Either: On manifold rail With through-hole
Pneumatic connection, port 1	G1/8
Pneumatic connection, port 2	G1/8
Pneumatic connection, port 3	G1/8
Pneumatic connection, port 4	G1/8
Pneumatic connection, port 5	G1/8
Note on materials	RoHS-compliant
Material seals	HNBR NBR
Material housing	Wrought aluminium alloy

Another size as below
