QH-QS-4-1/8 Pneumatic Manual Valve Festo Ball Valve 153486 GTIN4052568035020
Price:
EXW USD15-25
MOQ:
1pc
Delivery Time:
5-7 working days
Brand:
FESTO
Product Description
FESTO Ball valve QH-QS-4-1/8 153486 GTIN4052568035020 Pneumatic Manual Valve
About product
Male thread/push-in connector
Shut-off valve, manually operated
In-line installation, can be screwed in, bulkhead fitting
Variants: thread at both ends, push-in connector at both ends, thread/push-in connector
Technical Data
| Valve function | 2/2 double solenoid |
| Pneumatic connection, port 1 | R1/8 |
| Pneumatic connection, port 2 | QS-4 |
| Type of actuation | Manual |
| Type of mounting | Screw-in |
| Standard nominal flow rate | 235 l/min |
| Nominal size | 2.5 mm |
| Ambient temperature | 0°C-60°C |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Sealing principle | Soft |
| Design | Ball valve |
| Symbol | 00991458 |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Product weight | 14 g |
| Note on materials | RoHS-compliant |
Another size as below
| Type | Order no | Price |
| QH-QS-4 | 153483 | USD15-25 |
| QH-QS-6 | 153484 | USD15-25 |
| QH-QS-4-1/8 | 153486 | USD15-25 |
| QH-QS-6-1/8 | 153487 | USD15-25 |
| QHS-QS-6 | 153485 | USD15-25 |
Product picture
There are so many products, welcome to enquire!
