EV-20-4 150683 Pneumatic Air Cylinders Festo Clamping Module GTIN4052568069797
Price:
EXW USD30-40
MOQ:
1pc
Delivery Time:
7-10working days
Brand:
FESTO
Product Description
FESTO Clamping module EV-20-4 150683 GTIN4052568069797 Pneumatic Air Cylinders
About product
Design: Diaphragm
Cushioning: None
Position sensing: None
Mounting position: Any
Only operate the clamping module with a counter-stop
Choice of supply port connection by repositioning sealing plug
Clamping area
Technical Data
| Stroke | 4 mm |
| Clamping surface | Ø 20 |
| Mounting position | optional |
| Mode of operation | Single-acting |
| Symbol | 00991208 |
| Operating pressure | 0.6 MPa |
| Operating pressure | 6 bar |
| Operating pressure | 87 psi |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10 °C ... 40 °C |
| Product weight | 19 g |
| Type of mounting | With through-hole |
| Pneumatic connection | M3 |
| Material housing | Die-cast aluminium |
| Material membrane | TPE-U(PU) |
Another size as below
| TYPE | PART NO |
| EV-12-3 | 150681 |
| EV-16-4 | 150682 |
| EV-20-4 | 150683 |
| EV-25-4 | 150684 |
| EV-32-5 | 150685 |
| EV-40-5 | 150687 |
| EV-50-5 | 150688 |
| EV-63-5 | 150689 |
Package picture
