VUVG-S18-M52-MZT-G14-1T1L Pneumatic Solenoid Valves 8004880 GTIN4052568277451
Price:
EXW USD100-120
MOQ:
1pc
Delivery Time:
7-10working days
Brand:
FESTO
Product Description
FESTO Solenoid valve VUVG-S18-M52-MZT-G14-1T1L 8004880 GTIN4052568277451
About product
1.Reduce power consumption.
2.Excellent cost performance.
3.Optional quick connector.
4.Can have multiple pressure zones.
5.Sub-D derivative type and fieldbus interface derivative type have protection grade of IP67.
6.Internal pilot or external pilot can be realized on the same gas path plate through plug.
7.The plate valve with the working air port at the bottom is used for the installation of the control cabinet.
Technical Data
| Valve function | 5/2-way, monostable |
| Type of actuation | Electric |
| Valve size | 18 mm |
| Standard nominal flow rate | 1150 l/min |
| pneumatic working port | G1/4 |
| Operating voltage | 24V DC |
| Operating pressure- | 0.09 MPa ... 0.8 MPa |
| Operating pressure- | 0.9 bar ... 8 bar |
| Design | Piston gate valve |
| Type of reset | Mechanical spring |
| Approval | c UL us - Recognized (OL) |
| Degree of protection | IP65 IP67 |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Manual override | Detenting Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | External |
| Flow direction | Reversible |
| Symbol | 00991025 |
| lap | Indefinite overlap |
| Signal status display | LED |
| Pilot pressure | 0.3 MPa ... 0.8 MPa |
| Pilot pressure | 3 bar ... 8 bar |
| Max. switching frequency | 3 Hz |
| Switching time off | 50 ms |
| Switching time on | 13 ms |
| Duty cycle | 100% |
| Characteristic coil data | 22 V DC: 1.0 W |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -5°C-60°C |
| Pilot medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | -5°C-60°C |
| Product weight | 138 g |
| Electrical connection | Via sub-base |
| Type of mounting | On manifold rail |
| Pneumatic connection, port 2 | G1/4 |
| Pneumatic connection, port 4 | G1/4 |
| Note on materials | RoHS-compliant |
| Material seals | HNBR NBR |
| Material housing | Wrought aluminium alloy |
Package picture
