ISO Pneumatic Air Cylinders DSBC-100-125-PPVA-N3 1384809 GTIN4052568232375
Price:
EXW USD200-250
MOQ:
1pc
Delivery Time:
7-10working days
Brand:
FESTO
Product Description
FESTO ISO cylinder DSBC-100-125-PPVA-N3 1384809 GTIN4052568232375
About product
1.Extensive range of accessories makes it possible to install the cylinder virtually anywhere.
2.The variants can be configured according to individual needs using a modular product system.
3.Wide range of variants provides high level of flexibility.
4.Standards-based cylinders to ISO15552 (corresponds to the withdrawn standards ISO 6431, DIN ISO 6431, VDMA24562, NFE49003.1 and UNI 10290).
5.Double-acting.
6.For contactless position sensing.
7.Optionally with protection against rotation.
Technical Data
| Stroke | 125 mm |
| Piston diameter | 100 mm |
| Piston rod thread | M20x1.5 |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | optional |
| Conforms to standard | ISO 15552 |
| Piston-rod end | Male thread |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Symbol | 00991235 |
| Variants | Piston rod at one end |
| Operating pressure | 0.04 MPa ... 1.2 MPa |
| Operating pressure | 0.4 bar ... 12 bar |
| Mode of operation | Double-acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Impact energy in end positions | 2.5 J |
| Cushioning length | 31 mm |
| Basic weight for 0 mm stroke | 3665 g |
| Additional weight per 10 mm stroke | 101 g |
| Type of mounting | Either: Via female thread With accessories |
| Pneumatic connection | G1/2 |
| Note on materials | RoHS-compliant |
| Material cover | Die-cast aluminium, coated |
| Material piston seal | TPE-U(PU) |
| Material piston | Wrought aluminium alloy |
| Material piston rod | High-alloy steel |
| Material piston rod wiper | TPE-U(PU) |
| Buffer seal material | TPE-U(PU) |
| Cushioning piston material | POM |
| Material cylinder barrel | Smooth-anodised wrought aluminium alloy |
| Material nut | Galvanised steel |
| Material bearing | POM |
| Material collar screws | Galvanised steel |
Application examples
There are many models. Please hurry to me!
