Die Cast Zinc Festo Filter LF-D-5M-MIDI-A 192561 GTIN4052568152307
Price:
EXW USD50-60
MOQ:
1pc
Delivery Time:
7-10working days
Brand:
FESTO
Product Description
FESTO Filter LF-D-5M-MIDI-A 192561 GTIN4052568152307
About product
1.Good particle and condensate separation.
2.High flow rate with minimal pressure drop.
3.With or without connecting plates.
4.With manual or fully automatic condensate drain.
Technical Data
| Size | Midi |
| Series | D |
| Condensate drain | Fully automatic |
| Design | Sintered filter with centrifugal separator |
| Max. condensate volume | 43 ml |
| Bowl guard | Metal bowl guard |
| Symbol | 00991520 |
| Operating pressure | 2 bar ... 12 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:9:-] Inert gases |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Storage temperature | -10°C-60°C |
| Air purity class at output | Compressed air to ISO 8573-1:2010 [6:8:4] Inert gases |
| Media temperature | 5°C-60°C |
| Ambient temperature | 5°C-60°C |
| Product weight | 700 g |
| Type of mounting | In-line installation With accessories |
| Pneumatic connection, port 1 | Sub-base |
| Pneumatic connection, port 2 | Sub-base |
| Note on materials | RoHS-compliant |
| Material filter | PE |
| Material housing | Die-cast zinc |
| Material bowl | PC |
Peripherals overview
There are many models . Please hurry to me!
