ADN-80-14 -A-P-A 536351 Pneumatic Air Cylinders Festo Compact Cylinder
FESTO Compact cylinder,ADN-80-14 -A-P-A,536351
About product
1.Easy to mount with a comprehensive range of mounting accessories for just about every type of installation.
2.Highly flexible thanks to the wide range of variants.
3.Contactless position sensing using proximity sensors.
4.Optimised manufacturing methods, patented technology and more than 40 years of experience in the field of cylinders make Festo and ADN/AEN a great team.
5.Integrated cushioning for absorbing residual energy.
6.Long service life thanks to exceptional cushioning characteristics and minimal friction factors.
7.Colour:silver
Technical Data
| Stroke | 1 mm ... 500 mm |
| Piston diameter | 80 mm |
| Mounting position | optional |
| Conforms to standard | ISO 21287 |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Operating pressure | 0.06 MPa ... 1 MPa |
| Operating pressure | 0.6 bar ... 10 bar |
| Mode of operation | Double-acting |
| CE mark (see declaration of conformity) | To EU Explosion Protection Directive (ATEX) |
| CE marking (see declaration of conformity) | To UK EX instructions |
| ATEX category gas | II 2G |
| ATEX category dust | II 2D |
| Explosion ignition protection type for gas | Ex h IIC T4 Gb |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L VDMA24364 zone III |
| Ambient temperature | -40°C-120°C |
| Basic weight for 0 mm stroke | 1121 g |
| Additional weight per 10 mm stroke | 79 g |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material collar screws | Steel |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Smooth-anodised wrought aluminium alloy |
Technical data – Basic version and variants
There are many models. Please hurry to me!
