PBT Festo Pressure Regulator VRPA-CM-Q4-E 8086003 GTIN4052568458676
Price:
EXW USD50-60
MOQ:
1pc
Delivery Time:
5-7working days
Brand:
FESTO
Product Description
FESTO Pressure regulator VRPA-CM-Q4-E 8086003 GTIN4052568458676
About product
Regulates the operating pressure independently of the fluctuating inlet pressure
With secondary exhaust and with return flow function
Piston regulator with through pressure supply
Technical Data
| Pneumatic connection, port 1 | QS-4 |
| Pneumatic connection, port 2 | QS-4 |
| Type of mounting | With through-hole |
| Standard nominal flow rate | 80 l/min |
| Ambient temperature | 0°C-60°C |
| Material housing | PBT |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Mounting position | optional |
| Type of actuation | Manual |
| Adjustment component | Rotary knob with detent |
| Symbol | 00991558 |
| Pressure gauge (ANALOG) or Pressure display (DIGITAL) | With pressure gauge |
| Pressure regulation range | 0.1 MPa ... 0.8 MPa |
| Pressure regulation range | 1 bar ... 8 bar |
| Pressure regulation range | 14.5 psi ... 116 psi |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Product weight | 23 g |
| Note on materials | RoHS-compliant |
| Material static seals | NBR |
General technical data
There are many models. Please hurry to me!
