Double acting Festo Compact Cylinder DPDM-16-40-PA 4833191 GTIN4052568293062
Price:
EXW USD100-150
MOQ:
1pc
Delivery Time:
5-7working days
Brand:
FESTO
Product Description
FESTO Compact cylinder DPDM-16-40-PA 4833191 GTIN4052568293062
About product
1.All mounting interfaces of the compact cylinder DPDM are compatible with those of the compact cylinder DMM.
2.Compared to the DMM, however, the DPDM is noticeably shorter, giving a lower product weight for the same functionality.
3.Mounting using through-hole and female thread.
4.Compact design.
5.Piston rod variants.
Technical Data
| Stroke | 40 mm |
| Piston diameter | 16 mm |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Mode of operation | Double-acting |
| Design | Piston Piston rod Profile barrel |
| Position detection | Via proximity switch |
| Symbol | 00991217 |
| Variants | Piston rod at one end |
| Operating pressure | 0.15 MPa ... 0.8 MPa |
| Operating pressure | 1.5 bar ... 8 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | -10°C-80°C |
| Basic weight for 0 mm stroke | 66 g |
| Additional weight per 10 mm stroke | 13 g |
| Type of mounting | Either: With through-hole Via female thread |
| Pneumatic connection | M5 |
| Note on materials | RoHS-compliant |
| Material cover | Wrought aluminium alloy |
| Material seals | TPE-U(PU) |
| Material housing | Anodised wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
Application example
There are many models. Please hurry to me!
