Ball Screw Drive Electric Cylinder ESBF-BS-80-100-32P 574111 GTIN4052568222086
Price:
EXW USD1000-1500
MOQ:
1pc
Delivery Time:
5-7working days
Brand:
FESTO
Product Description
FESTO electric drive ESBF-BS-80-100-32P 574111 GTIN4052568222086
About product
1.Available with ball screw drive (size 32 … 100) or lead screw (size 32 … 50).
2.Ball screw: with three spindle pitches for selecting the optimal force-speed ratio.
3.Optional: high corrosion protection, degree of protection IP65, food-safe (see www.festo.com/certificates/ESBF), piston rod extension.
Advantage
1.High corrosion protection.
2.Degree of protection IP65.
3.Extended piston rod.
4.NSF-H1 lubricant for food & beverage industry applications.
5.Extensive accessories.
Technical Data
| Size | 80 |
| Stroke | 100 mm |
| Piston rod thread | M20x1.5 |
| Spindle diameter | 32 mm |
| Spindle pitch | 32 mm/U |
| Based on standard | ISO 15552 |
| Mounting position | optional |
| Piston-rod end | Male thread |
| Type of motor | Servo motor |
| Position detection | Via proximity switch |
| Design | Electric cylinder with ball screw |
| Spindle type | Ball screw |
| Symbol | 00991941 |
| Protection against torque/guide | With plain-bearing guide |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -20°C-60°C |
| Degree of protection | IP40 |
| Ambient temperature | 0°C-60°C |
| Basic weight for 0 mm stroke | 7393 g |
| Additional weight per 10 mm stroke | 155 g |
| Type of mounting | Via female thread Or accessories |
| Interface code, actuator | D80 |
| Note on materials | RoHS-compliant |
| Material cover | Cast aluminium, coated |
| Material piston rod | High-alloy stainless steel |
| Material screws | Galvanised steel |
| Material spindle nut | Rolled steel |
| Material cylinder barrel | Smooth-anodised wrought aluminium alloy |
General technical data
There are many models. Please hurry to me!
