Wrought Aluminium Alloy Festo Solenoid Valve VUVG-L14-B52-G18-P1 8033531 GTIN4052568428945
Price:
EXW USD50-80
MOQ:
1pc
Delivery Time:
5-7working days
Brand:
FESTO
Product Description
FESTO Solenoid valve VUVG-L14-B52-G18-P1 8033531 GTIN4052568428945
About product
1.Can be set to internal or external pilot air supply for manifold assemblies with sub-base valves.
2.Wide range of valve functions.
3.Choice of quick push-in connectors.
4.In-line valves.
5.Semi in-line valves for manifold assembly.
6.Sturdy and durable metal components.
Technical Data
| Valve function | 5/2 double solenoid |
| Type of actuation | Electric |
| Valve size | 14 mm |
| Standard nominal flow rate | 700 l/min ... 780 l/min |
| pneumatic working port | G1/8 |
| Operating pressure | 0.15 MPa ... 0.8 MPa |
| Operating pressure | 1.5 bar ... 8 bar |
| Design | Piston gate valve |
| Approval | c UL us - Recognized (OL) |
| Certificate issuing authority | UL MH19482 |
| Degree of protection | IP65 With electric pilot valve and plug socket |
| Nominal size | 5.6 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Type of piloting | Pilot actuated |
| Pilot air supply | Internal |
| Symbol | 00992897 |
| lap | Positive overlap |
| Pilot pressure | 0.15 MPa ... 0.8 MPa |
| Pilot pressure | 1.5 bar ... 8 bar |
| Suitability for vacuum | no |
| Switching time reversal | 12 ms |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -5°C-60°C |
| Ambient temperature | -5°C-60°C |
| Product weight | 65 g |
| Electrical connection | Via electric pilot valve |
| Type of mounting | Either: On manifold rail With through-hole |
| Pneumatic connection, port 1 | G1/8 |
| Pneumatic connection, port 2 | G1/8 |
| Pneumatic connection, port 3 | G1/8 |
| Pneumatic connection, port 4 | G1/8 |
| Pneumatic connection, port 5 | G1/8 |
| Pilot control interface | To ISO 15218 |
| Note on materials | RoHS-compliant |
| Material seals | HNBR NBR |
| Material housing | Wrought aluminium alloy |
Product package
There are many models. Please hurry to me!
