FESTO Pneumatic Solenoid Valves VUVG-L14-M52-A-G18-P1 8033529 GTIN4052568428921

Name: FESTO Pneumatic Solenoid Valves VUVG-L14-M52-A-G18-P1 8033529 GTIN4052568428921
Brand: Airwolf Automation

Price Negotiable

Price: EXW USD50-80

MOQ: 1pc

Delivery Time: 5-7working days

Brand: FESTO

Product Description

FESTO Solenoid valve VUVG-L14-M52-A-G18-P1 8033529 GTIN4052568428921

About product

1.Secure wall mounting or H-rail mounting.

2.Easy mounting, captive screws and seal.

3.Connection technology easy to change via the electrical sub-base.

4.Identification holder for labelling the valves.

5.The electrical connection is established via different E-boxes.

Technical Data

Valve function	5/2-way, monostable
Type of actuation	Electric
Valve size	14 mm
Standard nominal flow rate	700 l/min ... 780 l/min
pneumatic working port	G1/8
Operating pressure	0.25 MPa ... 0.8 MPa
Operating pressure	2.5 bar ... 8 bar
Design	Piston gate valve
Type of reset	Pneumatic spring
Approval	c UL us - Recognized (OL)
Certificate issuing authority	UL MH19482
Degree of protection	IP65 With electric pilot valve and plug socket
Nominal size	5.6 mm
Exhaust-air function	With flow control option
Sealing principle	Soft
Mounting position	optional
Type of piloting	Pilot actuated
Pilot air supply	Internal
Symbol	00992908
lap	Positive overlap
Pilot pressure	0.25 MPa ... 0.8 MPa
Pilot pressure	2.5 bar ... 8 bar
Suitability for vacuum	no
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Media temperature	-5°C-60°C
Ambient temperature	-5°C-60°C
Product weight	66 g
Electrical connection	Via electric pilot valve
Type of mounting	Either: On manifold rail With through-hole
Pneumatic connection, port 1	G1/8
Pneumatic connection, port 2	G1/8
Pneumatic connection, port 3	G1/8
Pneumatic connection, port 4	G1/8
Pneumatic connection, port 5	G1/8
Pilot control interface	To ISO 15218
Note on materials	RoHS-compliant
Material seals	HNBR NBR
Material housing	Wrought aluminium alloy
