Aluminium Alloy Festo Clamping Module EV-16-4 150682 GTIN4052568010331
Price:
EXW USD30-40
MOQ:
1pc
Delivery Time:
7-10working days
Brand:
FESTO
Product Description
FESTO Clamping module EV-16-4 150682 GTIN4052568010331
About product
1.Material: Wrought aluminium alloy.
2.Foot mounting HBEV for clamping module, rectangular.
3.Compact rodless cylinder with diaphragm.
4.Single-acting, with reset function.
5.Flat design.
Technical Data
| Stroke | 4mm |
| Clamping surface | Diameter 16 |
| Mounting position | optional |
| Mode of operation | Single-acting |
| Symbol | 00991208 |
| Operating pressure | 0.6 MPa |
| Operating pressure | 6 bar |
| Operating pressure | 87 psi |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10°C-40°C |
| Product weight | 15 g |
| Type of mounting | With through-hole |
| Pneumatic connection | M3 |
| Material housing | Die-cast aluminium |
| Material membrane | TPE-U(PU) |
Ordering data – Clamping module, round
