Aluminium Alloy One Way Air Flow Control Valves GRLZ-1/8-QS-6-D 193158
Price:
EXW USD20-40
MOQ:
1pc
Delivery Time:
7-10working days
Brand:
FESTO
Product Description
FESTO One-way flow control valve GRLZ-1/8-QS-6-D 193158 GTIN4052568043896
About product
1.Supply air oneway flow control function.
2.Can be rotated 360° around the screwin axis after installation.
3.The standard flow rate qn is measured at an operating pressure of p1 = 6 bar and an output pressure with respect to atmospheric pressure (p2 = 0 bar).
Technical Data
| Valve function | Supply air one-way flow control function |
| Pneumatic connection, port 1 | QS-6 |
| Pneumatic connection, port 2 | G1/8 |
| Adjustment component | Slotted head screw |
| Type of mounting | Screw-in |
| Standard nominal flow rate in flow control direction | 185 l/min |
| Mounting position | optional |
| Symbol | 00991453 |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Nominal torque | 3 Nm |
| Product weight | 22 g |
| Material screw-in stud | Wrought aluminium alloy |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
| Material release ring | POM |
| Material adjusting screw | Brass |
| Material swivel fitting | Die-cast zinc Chromated |
Operating and environmental conditions
A wide range of products with excellent prices. Please contact me!
