T Slot Festo Proximity Sensor SME-8-K-LED-24 150855 GTIN4052568010409
Price:
EXW USD50-60
MOQ:
1pc
Delivery Time:
7-10working days
Brand:
FESTO
Product Description
FESTO Proximity sensor SME-8-K-LED-24 150855 GTIN4052568010409
About product
1.Connecting cable, 3-wire cable, 3 x 0.14 mm².
2.Yellow light emitting diode.
3.Max. tightening torque 0.2 Nm.
Technical Data
| Design | For T-slot |
| Conforms to standard | EN 60947-5-2 |
| Symbol | 00991620 |
| Approval | RCM trademark |
| Note on materials | RoHS-compliant |
| Measured variable | Position |
| Measuring principle | Magnetic reed |
| Ambient temperature | -40°C-60°C |
| Switching output | Contacting, bipolar |
| Max. output current | 500 mA |
| Connection outlet orientation | In-line |
| Cable length | 2.5 m |
| Cable sheath colour | grey |
| Material cable sheath | TPE-U(PUR) |
| Type of mounting | Clamped in T-slot Insertable in the slot lengthwise |
| Tightening torque | 0.2 Nm |
| Mounting position | optional |
| Product weight | 30 g |
| Housing colour | Black |
| Switching status indication | Yellow LED |
| Degree of protection | IP65 IP67 |
| LABS (PWIS) conformity | VDMA24364-B2-L |
Ordering data
There are many models . Please contact me!
