5/3 Closed Pneumatic Solenoid Valves VSVA-B-P53C-H-A1-1C1 546708 GTIN4052568184919
Price:
EXW USD100-150
MOQ:
1pc
Delivery Time:
7-10 working days
Brand:
FESTO
Product Description
FESTO Solenoid valve VSVA-B-P53C-H-A1-1C1 546708 GTIN4052568184919
About product
1.Valves can be replaced under pressure using a vertical pressure shut-off plate.
2.Wide range of valve functions.
3.Vertical supply plates permit a flexible air supply and variable pressure zones.
Technical Data
| Valve function | 5/3 closed |
| Type of actuation | Electric |
| Valve size | 26 mm |
| Operating voltage | 24V DC |
| Approval | c UL us - Recognized (OL) |
| Degree of protection | IP65 NEMA 4 |
| Nominal size | 9 mm |
| Exhaust-air function | With flow control option |
| Sealing principle | Soft |
| Mounting position | optional |
| Conforms to standard | ISO 15407-1 VDMA 24563 |
| Manual override | Non-detenting |
| Type of piloting | Pilot actuated |
| Pilot air supply | Internal |
| Flow direction | Non-reversible |
| Symbol | 00991080 |
| lap | Positive overlap |
| Signal status display | LED |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Product weight | 305 g |
| Type of mounting | On sub-base |
| Note on materials | RoHS-compliant |
| Material seals | HNBR NBR |
| Material housing | Die-cast aluminium |
| Material screws | Steel Galvanised |
About product
There are many models and types, welcome to enquiry!
