Pneumatic System Festo On / Off Valve HE-1/2-D-MIDI 162810 GTIN4052568012748
Price:
EXW USD80-100
MOQ:
1pc
Delivery Time:
7-12working days
Brand:
FESTO
Product Description
FESTO On/off valve HE-1/2-D-MIDI 162810 GTIN4052568012748
About product
1.Ducted exhaust air possible via a threaded connection.
2.The switching position is recognisable.
3.Commercially available padlock for security.
4.3/2-way manual shut-off valve.
5.The unit is exhausted when switched off.
Technical Data
| Design | Piston gate valve |
| Type of actuation | Manual |
| Sealing principle | Soft |
| Exhaust-air function | Without flow control option |
| Manual override | None |
| Symbol | 00995571 |
| Valve function | 3/2 double solenoid |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| Note on materials | RoHS-compliant |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Type of mounting | In-line installation With accessories |
| Mounting position | optional |
| Flow direction | Non-reversible |
| Product weight | 511 g |
| Pneumatic connection, port 1 | G1/2 |
| Pneumatic connection, port 2 | G1/2 |
| Pneumatic connection, port 3 | G1/4 |
| Air purity class at output | Compressed air to ISO 8573-1:2010 [7:4:4] Inert gases |
| Material seals | NBR |
| Material housing | Die-cast aluminium |
Picture about package
There are so many models . Please contact with me!
