QS-8-6 153038 FESTO Push In Connector GTIN4052568031411
Price:
EXW USD1-2
MOQ:
1 PCS
Delivery Time:
7-10 working days
Brand:
FESTO
Product Description
FESTO Push-in connector QS-8-6 153038 GTIN4052568031411
About product
1.Wide range of applications.
2.With a variety of combinations of different models, it has a high flexibility in various standard applications Activity.
3.Color:Blue.
4.Material Material housing:PBT.
5.Material tubing clamp component:High-alloy stainless steel.
Product Technical Data
| Size | Standard |
| Nominal size | 4.3 mm |
| Mounting position | optional |
| Size of pack | 10 |
| Design | Push-pull principle |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Product weight | 8.8 g |
| Pneumatic connection, port 1 | For tubing outer diameter of 8 mm |
| Pneumatic connection, port 2 | For tubing outside diameter of 6 mm |
| Colour of release ring | Blue |
| Note on materials | RoHS-compliant |
| Material housing | PBT |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
Packages
There are so many models, best price and fast delivery time. Welcome to enquiry.
