QS-1/8-8 153004 FESTO Push In Tube Fittings GTIN4052568031145
Price:
EXW USD2-3
MOQ:
1 PCS
Delivery Time:
5-7working days
Brand:
FESTO
Product Description
FESTO Push-in fitting QS-1/8-8 153004 GTIN4052568031145 Tube Fittings
About product
1.Stainless steel push-in fitting.
2.Maximum corrosion resistance CRC 4 and chemical resistance.
3.For pneumatic applications with a temperature range up to 150°C and a pressure range up to 16 bar.
Product Technical Data
| Size | Standard |
| Nominal size | 6 mm |
| Type of seal on screw-in stud | Coating |
| Mounting position | optional |
| Size of pack | 10 |
| Design | Push-pull principle |
| Note on operating and pilot medium | Lubricated operation possible |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -10°C-80°C |
| Product weight | 14 g |
| Pneumatic connection, port 1 | Male thread R1/8 |
| Pneumatic connection, port 2 | For tubing outside diameter of 8 mm |
| Colour of release ring | Blue |
| Note on materials | RoHS-compliant |
| Material housing | Brass Nickel-plated |
| Material release ring | POM |
| Material tubing seal | NBR |
| Material tubing clamp component | High-alloy stainless steel |
Possible push-in fitting/tubing combinations
There are so many models, best price and fast delivery time. Welcome to enquiry and contact with me.Wait for you!
