159631 Pneumatic System Components FESTO Filter Regulator LFR-1/4-D-MINI
Price:
USD 40-50
MOQ:
1 PC
Delivery Time:
7-10 working Days
Brand:
FESTO
Product Description
FESTO filter regulator LFR-1/4-D-MINI 159631 Pneumatic System Components
About Product
Good regulation characteristics with minimal hysteresis
Good particle separation and high flow rate
Space-saving design with filter and regulator in a single unit
Technical data
| Size | Mini |
| Series | D |
| Actuator lock | Rotary knob with detent |
| Grade of filtration | 40 µm |
| Condensate drain | Manually rotating |
| Design | Filter regulator with pressure gauge |
| Max. condensate volume | 22 ml |
| Bowl guard | Metal bowl guard |
| Symbol | 00991585 |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Storage temperature | -10°C-60°C |
| Media temperature | -10°C-60°C |
| Ambient temperature | -10°C-60°C |
| Product weight | 460 g |
| Pneumatic connection, port 1 | G1/4 |
| Pneumatic connection, port 2 | G1/4 |
| Note on materials | RoHS-compliant |
| Material housing | Die-cast zinc |
| Material bowl | PC |
Standard nominal flow rate qnN1) [l/min]
There are so many models ,please contact with me.
